Cloning of UpNOA1 Gene from Ulmus pumila L. and Screening of Its Interacting Proteins

doi:10.13560/j.cnki.biotech.bull.1985.2024-1143

Abstract

Abstract:

Objective Nitric oxide-related protein NOA1 is associated to the levels of NO in plants, which may be involved in various physiological activities of plants. The UpNOA1 gene was cloned, its tissue-specific expression in elm (Ulmus pumila L.) was analyzed, and the proteins interacting with UpNOA1 was screened, which may provide the basis for studying the function of UpNOA1 in elm. Method Ulmus pumila L. was used as the experimental material, and the NO-related UpNOA1 gene was cloned. The domain architecture and phylogenetic relationships were analyzed using bioinformatics approaches. Tissue-specific expression of UpNOA1 was assessed via RT-qPCR. A vector was constructed for prokaryotic expression analysis, and the resulting UpNOA1 protein was purified. Finally, the UpNOA1 interaction proteins were screened and analyzed by His-PULL DOWN. Result The UpNOA1 gene possesses a 1 698 bp open reading frame, encoding 565 amino acids and containing a conserved GTP/Mg²⁺ binding sites. Subcellular localization prediction using Plant-mPLoc indicated that the UpNOA1 protein is targeted to chloroplasts. Phylogenetic analysis revealed that the UpNOA1 protein shows the highest sequence homology to UaNOA1 protein from American elm (Ulmus americana) and clusters with it in the phylogenetic tree. RT-qPCR analysis revealed that the expression of UpNOA1 gene is the highest in the leaves, followed by the seeds. A total of 131 proteins were identified as UpNOA1-interacting proteins via His-PULL DOWN assay. KEGG and GO enrichment analyses indicated a predominance of ribosomal proteins is associated with genetic information processing among the interacting proteins. Following annotation and comparison, a list of 25 candidate proteins potentially involved in stress resistance and GTP binding was compiled. Conclusion UpNOA1 gene is cloned. The highest expression is found in leaves, followed by elm seeds. A total of 131 UpNOA1 interacting proteins are identified, of which 25 are associated with stress resistance and GTP binding.

Key words: Ulmus pumila L., NOA1, tissue specific expression, PULL DOWN, interaction protein

LIU Xiao-tian, HE Yu-qi, LIU Chang, XUE Hua. Cloning of UpNOA1 Gene from Ulmus pumila L. and Screening of Its Interacting Proteins[J]. Biotechnology Bulletin, 2025, 41(6): 297-306.

Figures/Tables 9

References 41

1	王亚骋. 木本食材活性成分研究 [D]. 郑州: 河南农业大学, 2022.
	Wang YC. Study on active components of woody food materials [D]. Zhengzhou: Henan Agricultural University, 2022.
2	Jeong C, Lee CH, Seo J, et al. Catechin and flavonoid glycosides from the Ulmus genus: exploring their nutritional pharmacology and therapeutic potential in osteoporosis and inflammatory conditions [J]. Fitoterapia, 2024, 178: 106188.
3	Kim I, Seo J, Lee DH, et al. Ulmus davidiana 60% edible ethanolic extract for prevention of pericyte apoptosis in diabetic retinopathy [J]. Front Endocrinol, 2023, 14: 1138676.
4	Kim K, Veerappan K, Woo N, et al. Ulmus macrocarpa Hance extract modulates intestinal microbiota in healthy adults: a randomized, placebo-controlled clinical trial [J]. J Microbiol, 2021, 59(12): 1150-1156.
5	张畅, 姜卫兵, 韩健. 论榆树及其在园林绿化中的应用 [J]. 中国农学通报, 2010, 26(10): 202-206.
	Zhang C, Jiang WB, Han J. On Ulmus pumila Linn. and its application in landscape architecture [J]. Chin Agric Sci Bull, 2010, 26(10): 202-206.
6	陈昂, 杨秀春, 徐斌, 等. 基于面向对象与深度学习的榆树疏林识别方法研究 [J]. 地球信息科学学报, 2020, 22(9): 1897-1909.
	Chen A, Yang XC, Xu B, et al. Research on recognition methods of elm sparse forest based on object-based image analysis and deep learning [J]. J Geo Inf Sci, 2020, 22(9): 1897-1909.
7	Corpas FJ, González-Gordo S, Cañas A, et al. Nitric oxide and hydrogen sulfide in plants: which comes first? [J]. J Exp Bot, 2019, 70(17): 4391-4404.
8	Ciacka K, Staszek P, Sobczynska K, et al. Nitric oxide in seed biology [J]. Int J Mol Sci, 2022, 23(23): 14951.
9	Zhang Y, Wang RR, Wang XD, et al. Nitric oxide regulates seed germination by integrating multiple signalling pathways [J]. Int J Mol Sci, 2023, 24(10): 9052.
10	Corpas FJ, González-Gordo S, Palma JM. NO source in higher plants: present and future of an unresolved question [J]. Trends Plant Sci, 2022, 27(2): 116-119.
11	Allagulova CR, Lubyanova AR, Avalbaev AM. Multiple ways of nitric oxide production in plants and its functional activity under abiotic stress conditions [J]. Int J Mol Sci, 2023, 24(14): 11637.
12	Moreau M, Lee GI, Wang YZ, et al. AtNOS/AtNOA1 is a functional Arabidopsis thaliana cGTPase and not a nitric-oxide synthase [J]. J Biol Chem, 2008, 283(47): 32957-32967.
13	Xie YJ, Mao Y, Lai DW, et al. Roles of NIA/NR/NOA1-dependent nitric oxide production and HY1 expression in the modulation of Arabidopsis salt tolerance [J]. J Exp Bot, 2013, 64(10): 3045-3060.
14	Wiśniewski JR, Zougman A, Nagaraj N, et al. Universal sample preparation method for proteome analysis [J]. Nat Meth, 2009, 6: 359-362.
15	Astier J, Gross I, Durner J. Nitric oxide production in plants: an update [J]. J Exp Bot, 2018, 69(14): 3401-3411.
16	石武良. 拟南芥一氧化氮合成相关蛋白(AtNOA1)的生物学功能研究 [D]. 厦门: 厦门大学, 2009.
	Shi WL. Study on biological function of nitric oxide associated protein 1 (AtNOA1) in Arabidopsis thaliana [D]. Xiamen: Xiamen University, 2009.
17	Wang JY, Chitsaz F, Derbyshire MK, et al. The conserved domain database in 2023 [J]. Nucleic Acids Res, 2023, 51(D1): D384-D388.
18	Liu XW, Liu B, Xue SD, et al. Cucumber (Cucumis sativus L.) nitric oxide synthase associated Gene1 (CsNOA1) plays a role in chilling stress [J]. Front Plant Sci, 2016, 7: 1652.
19	Du ST, Zhang RR, Zhang P, et al. Elevated CO₂-induced production of nitric oxide (NO) by NO synthase differentially affects nitrate reductase activity in Arabidopsis plants under different nitrate supplies [J]. J Exp Bot, 2016, 67(3): 893-904.
20	Zhao G, Zhao YY, Yu XL, et al. Nitric oxide is required for melatonin-enhanced tolerance against salinity stress in rapeseed (Brassica napus L.) seedlings [J]. Int J Mol Sci, 2018, 19(7): 1912.
21	Santisree P, Sanivarapu H, Gundavarapu S, et al. Nitric oxide as a signal in inducing secondary metabolites during plant stress [M]//Co-Evolution of Secondary Metabolites. Cham: Springer International Publishing, 2020: 593-621.
22	Lozano-Juste J, León J. Enhanced abscisic acid-mediated responses in nia1nia2noa1-2 triple mutant impaired in NIA/NR- and AtNOA1-dependent nitric oxide biosynthesis in Arabidopsis [J]. Plant Physiol, 2010, 152(2): 891-903.
23	Heidler J, Al-Furoukh N, Kukat C, et al. Nitric oxide-associated protein 1 (NOA1) is necessary for oxygen-dependent regulation of mitochondrial respiratory complexes [J]. J Biol Chem, 2011, 286(37): 32086-32093.
24	Kolanczyk M, Pech M, Zemojtel T, et al. NOA1 is an essential GTPase required for mitochondrial protein synthesis [J]. Mol Biol Cell, 2011, 22(1): 1-11.
25	Al-Furoukh N, Kardon JR, Krüger M, et al. NOA1, a novel ClpXP substrate, takes an unexpected nuclear detour prior to mitochondrial import [J]. PLoS One, 2014, 9(7): e103141.
26	王进. AtNOAl响应SA调节拟南芥根波动性生长机制研究 [D]. 开封: 河南大学, 2013.
	Wang J. Mechanism of AtNOA1 in regulation of SA induced root waving in Arabidopsis thaliana [D]. Kaifeng: Henan University, 2013.
27	Li CL, Shen Y, Meeley R, et al. Embryo defective 14 encodes a plastid-targeted cGTPase essential for embryogenesis in maize [J]. Plant J, 2015, 84(4): 785-799.
28	Hillen HS, Lavdovskaia E, Nadler F, et al. Structural basis of GTPase-mediated mitochondrial ribosome biogenesis and recycling [J]. Nat Commun, 2021, 12(1): 3672.
29	Kondadi AK, Anand R, Reichert AS. Cristae membrane dynamics-A paradigm change [J]. Trends Cell Biol, 2020, 30(12): 923-936.
30	Gruffaz C, Smirnov A. GTPase Era at the heart of ribosome assembly [J]. Front Mol Biosci, 2023, 10: 1263433.
31	Loh PC, Morimoto T, Matsuo Y, et al. The GTP-binding protein YqeH participates in biogenesis of the 30S ribosome subunit in Bacillus subtilis [J]. Genes Genet Syst, 2007, 82(4): 281-289.
32	Hwang J, Inouye M. The tandem GTPase, Der, is essential for the biogenesis of 50S ribosomal subunits in Escherichia coli [J]. Mol Microbiol, 2006, 61(6): 1660-1672.
33	Qi YF, Zhao J, An R, et al. Mutations in circularly permuted GTPase family genes AtNOA1/RIF1/SVR10 and BPG2 suppress var2-mediated leaf variegation in Arabidopsis thaliana [J]. Photosynth Res, 2016, 127(3): 355-367.
34	Yang QS, He H, Li HY, et al. NOA1 functions in a temperature-dependent manner to regulate chlorophyll biosynthesis and Rubisco formation in rice [J]. PLoS One, 2011, 6(5): e20015.
35	张玲玲, 吴丹, 赵子捷, 等. 植物一氧化氮信号分子的研究进展 [J]. 植物学报, 2017, 52(3): 337-345.
	Zhang LL, Wu D, Zhao ZJ, et al. Research progress in nitric oxide signaling molecule in plants [J]. Chin Bull Bot, 2017, 52(3): 337-345.
36	Chen LT, Shiotani K, Togashi T, et al. Analysis of the Rac/Rop small GTPase family in rice: expression, subcellular localization and role in disease resistance [J]. Plant Cell Physiol, 2010, 51(4): 585-595.
37	高媛, 薛艳红, 刘士平. 植物抗氧化动态平衡研究进展 [J]. 生物资源, 2019, 41(1): 14-21.
	Gao Y, Xue YH, Liu SP. Advances in antioxidative stress metabolism in plants [J]. Biotic Resour, 2019, 41(1): 14-21.
38	Ahmad B, Mukarram M, Choudhary S, et al. Adaptive responses of nitric oxide (NO) and its intricate dialogue with phytohormones during salinity stress [J]. Plant Physiol Biochem, 2024, 208: 108504.
39	Sánchez-Vicente I, Lechón T, Fernández-Marcos M, et al. Nitric oxide alters the pattern of auxin maxima and PIN-FORMED1 during shoot development [J]. Front Plant Sci, 2021, 12: 630792.
40	Liu M, Zhang HH, Fang XZ, et al. Auxin acts downstream of ethylene and nitric oxide to regulate magnesium deficiency-induced root hair development in Arabidopsis thaliana [J]. Plant Cell Physiol, 2018, 59(7): 1452-1465.
41	Yu YQ, Tang WX, Lin WW, et al. ABLs and TMKs are co-receptors for extracellular auxin [J]. Cell, 2023, 186(25): 5457-5471.

引物Primer	序列Sequence （5′‒3′）
UpNOA1 PCR F	ATGGCGTCCAAAACCCTCTC
UpNOA1 PCR R	TCAAAAATACCATCTTGGTCTTGTT
UpNOA1 pMAL F	TCCATGGGCGATATCGGATCCATGGCGTCCAAAACCCTCTCAAC
UpNOA1 pMAL R	TTAATTACCTGCAGGGAATTCGTGATGGTGATGGTGATGGTGATGAAAATACCATCTT
qUpActin F	TATAATGAATTGCGTGTAGCCC
qUpActin R	CATAGCAGGAGTGTTGAAGGTC
qUpNOA1 F	CATCTTGAAGGCTCTACCGG
qUpNOA1 R	TTGTAACCCTTTCCACTCCTG

引物Primer	序列Sequence （5′‒3′）
UpNOA1 PCR F	ATGGCGTCCAAAACCCTCTC
UpNOA1 PCR R	TCAAAAATACCATCTTGGTCTTGTT
UpNOA1 pMAL F	TCCATGGGCGATATCGGATCCATGGCGTCCAAAACCCTCTCAAC
UpNOA1 pMAL R	TTAATTACCTGCAGGGAATTCGTGATGGTGATGGTGATGGTGATGAAAATACCATCTT
qUpActin F	TATAATGAATTGCGTGTAGCCC
qUpActin R	CATAGCAGGAGTGTTGAAGGTC
qUpNOA1 F	CATCTTGAAGGCTCTACCGG
qUpNOA1 R	TTGTAACCCTTTCCACTCCTG

序号 Serial number	蛋白名称 Protein name	功能注释 Function annotation	分子量 Molecular weight （kD）	等电点 Isoelectric point	蛋白特征性肽段数量 Number of characteristic peptides
1	TRINITY_DN4364_c1_g2	预测：热休克70 kD蛋白，线粒体［葡萄（Vitis vinifera）］	30.1	9.47	1
2	TRINITY_DN3442_c0_g1	18.1 kD I类热休克蛋白样蛋白［开心果（Pistacia vera）］	17.9	5.77	1
3	TRINITY_DN3511_c0_g1	16.9 kD 热休克蛋白［白桦（Betula platyphylla）］	17.5	5.71	4
4	TRINITY_DN4927_c0_g1	11S球蛋白前体同工型1A ［爱玉子（Ficus pumila var. awkeotsang）］	63.2	7.02	24
5	TRINITY_DN1797_c0_g1	11-S种子储藏蛋白［安德森寄生木（Parasponia andersonii）］	67.4	6.83	25
6	TRINITY_DN7461_c0_g1	类似球蛋白的种子储藏蛋白 At2g28490 ［显著桑（Morus notabilis）］	63.1	6.01	14
7	TRINITY_DN14490_c0_g1	晚期胚胎发生丰富蛋白，第3类［显著桑（Morus notabilis）］	14.1	4.92	5
8	TRINITY_DN17317_c0_g1	2-Cys过氧化物还原酶BAS1，叶绿体［普通山羊草（Aegilops tauschii subsp. tauschii）］	26.9	6.35	1
9	TRINITY_DN28842_c0_g1	甘油醛-3-磷酸脱氢酶，胞质型［向日葵（Helianthus annuus）］	21.7	5.95	2
10	TRINITY_DN1098_c0_g5	超氧化物歧化酶，部分序列［欧洲山毛榉（Fagus sylvatica）］	18.5	7.09	2
11	TRINITY_DN4794_c0_g1	种子生物素结合蛋白SBP65类似蛋白［石榴（Punica granatum）］	34.1	6.61	1
12	TRINITY_DN6469_c0_g1	抗渗蛋白类似蛋白［加州栎（Quercus lobata）］	27.0	7.61	4
13	TRINITY_DN5650_c0_g3	假定蛋白 EUGRSUZ_I01938 ［巨桉（Eucalyptus grandis）］	21.5	9.72	3
14	TRINITY_DN17167_c0_g1	光合作用NDH复合体类囊体腔定位亚基5 （PNSL5），叶绿体［向日葵（Helianthus annuus）］	20.5	8.68	1
15	TRINITY_DN12443_c0_g1	未注释蛋白 LOC115700795 同工型 X2 ［大麻（Cannabis sativa）］	19.9	7.88	5
16	TRINITY_DN10189_c0_g1	富甘氨酸蛋白2类似蛋白［枣（Ziziphus jujuba）］	18.9	6.74	2
17	TRINITY_DN18240_c0_g1	富甘氨酸RNA结合蛋白［番茄（Solanum lycopersicum）］	17.3	5.71	1
18	TRINITY_DN4384_c0_g1	预测：有丝分裂检查点蛋白BUB3.3类似蛋白［欧洲野草莓（Fragaria vesca subsp. vesca）］	17.4	5.99	5
19	TRINITY_DN175_c4_g1	预测：UPF0098蛋白 CPn_0877/CP_0992/CPj0877/CpB0906 ［梅花（Prunus mume）］	18.4	5.59	5
20	TRINITY_DN43339_c0_g1	假定蛋白 EW026_g2737 ［Phlebia centrifuga］	24.0	6.05	1
21	TRINITY_DN12101_c0_g2	GTP结合蛋白SAR1A类似蛋白［Rhodamnia argentea］	22.1	7.47	5
22	TRINITY_DN17498_c0_g5	推定小GTP酶超家族，Rab类型［牛樟（Cinnamomum micranthum f. kanehirae）］	11.7	9.41	1
23	TRINITY_DN6469_c0_g1	类渗透蛋白［加州栎（Quercus lobata）］	27.0	7.61	4
24	TRINITY_DN12488_c0_g1	生长素结合蛋白ABP19a类似蛋白［月季（Rosa chinensis）］	21.5	9.06	1
25	TRINITY_DN1250_c0_g1	推定4-羟基-4-甲基-2-氧代戊二酸醛缩酶2 ［桑树（Morus notabilis）］	17.7	5.99	3

序号 Serial number	蛋白名称 Protein name	功能注释 Function annotation	分子量 Molecular weight （kD）	等电点 Isoelectric point	蛋白特征性肽段数量 Number of characteristic peptides
1	TRINITY_DN4364_c1_g2	预测：热休克70 kD蛋白，线粒体［葡萄（Vitis vinifera）］	30.1	9.47	1
2	TRINITY_DN3442_c0_g1	18.1 kD I类热休克蛋白样蛋白［开心果（Pistacia vera）］	17.9	5.77	1
3	TRINITY_DN3511_c0_g1	16.9 kD 热休克蛋白［白桦（Betula platyphylla）］	17.5	5.71	4
4	TRINITY_DN4927_c0_g1	11S球蛋白前体同工型1A ［爱玉子（Ficus pumila var. awkeotsang）］	63.2	7.02	24
5	TRINITY_DN1797_c0_g1	11-S种子储藏蛋白［安德森寄生木（Parasponia andersonii）］	67.4	6.83	25
6	TRINITY_DN7461_c0_g1	类似球蛋白的种子储藏蛋白 At2g28490 ［显著桑（Morus notabilis）］	63.1	6.01	14
7	TRINITY_DN14490_c0_g1	晚期胚胎发生丰富蛋白，第3类［显著桑（Morus notabilis）］	14.1	4.92	5
8	TRINITY_DN17317_c0_g1	2-Cys过氧化物还原酶BAS1，叶绿体［普通山羊草（Aegilops tauschii subsp. tauschii）］	26.9	6.35	1
9	TRINITY_DN28842_c0_g1	甘油醛-3-磷酸脱氢酶，胞质型［向日葵（Helianthus annuus）］	21.7	5.95	2
10	TRINITY_DN1098_c0_g5	超氧化物歧化酶，部分序列［欧洲山毛榉（Fagus sylvatica）］	18.5	7.09	2
11	TRINITY_DN4794_c0_g1	种子生物素结合蛋白SBP65类似蛋白［石榴（Punica granatum）］	34.1	6.61	1
12	TRINITY_DN6469_c0_g1	抗渗蛋白类似蛋白［加州栎（Quercus lobata）］	27.0	7.61	4
13	TRINITY_DN5650_c0_g3	假定蛋白 EUGRSUZ_I01938 ［巨桉（Eucalyptus grandis）］	21.5	9.72	3
14	TRINITY_DN17167_c0_g1	光合作用NDH复合体类囊体腔定位亚基5 （PNSL5），叶绿体［向日葵（Helianthus annuus）］	20.5	8.68	1
15	TRINITY_DN12443_c0_g1	未注释蛋白 LOC115700795 同工型 X2 ［大麻（Cannabis sativa）］	19.9	7.88	5
16	TRINITY_DN10189_c0_g1	富甘氨酸蛋白2类似蛋白［枣（Ziziphus jujuba）］	18.9	6.74	2
17	TRINITY_DN18240_c0_g1	富甘氨酸RNA结合蛋白［番茄（Solanum lycopersicum）］	17.3	5.71	1
18	TRINITY_DN4384_c0_g1	预测：有丝分裂检查点蛋白BUB3.3类似蛋白［欧洲野草莓（Fragaria vesca subsp. vesca）］	17.4	5.99	5
19	TRINITY_DN175_c4_g1	预测：UPF0098蛋白 CPn_0877/CP_0992/CPj0877/CpB0906 ［梅花（Prunus mume）］	18.4	5.59	5
20	TRINITY_DN43339_c0_g1	假定蛋白 EW026_g2737 ［Phlebia centrifuga］	24.0	6.05	1
21	TRINITY_DN12101_c0_g2	GTP结合蛋白SAR1A类似蛋白［Rhodamnia argentea］	22.1	7.47	5
22	TRINITY_DN17498_c0_g5	推定小GTP酶超家族，Rab类型［牛樟（Cinnamomum micranthum f. kanehirae）］	11.7	9.41	1
23	TRINITY_DN6469_c0_g1	类渗透蛋白［加州栎（Quercus lobata）］	27.0	7.61	4
24	TRINITY_DN12488_c0_g1	生长素结合蛋白ABP19a类似蛋白［月季（Rosa chinensis）］	21.5	9.06	1
25	TRINITY_DN1250_c0_g1	推定4-羟基-4-甲基-2-氧代戊二酸醛缩酶2 ［桑树（Morus notabilis）］	17.7	5.99	3
