Research Progress in Liquid-liquid Extraction Technology for In Situ Extraction of Medium Chain Carboxylic Acids

doi:10.13560/j.cnki.biotech.bull.1985.2025-1171

Abstract

Abstract:

Medium chain carboxylic acids (MCCAs), as high-value platform chemicals, show extensive applications in food, chemical, pharmaceutical, and biomaterial industries due to their unique physicochemical properties. There are numerous technical bottlenecks, including high dependence on petrochemical resources, low product yield and purity, high energy consumption, and poor stability of the vegetable oil raw material supply chain in traditional chemical synthesis methods for producing MCCAs. Existing production capacity can no longer meet the rapidly growing market demand. Therefore, the application of microbial carbon chain elongation technology to convert waste biomass into high-value MCCAs not only facilitates the recycling of organic carbon sources, but also mitigates reliance on fossil resources. This synergistically integrates environmental sustainability, economic viability, and industrial scalability, positioning it as a highly promising strategy in green biomanufacturing. However, the efficient separation technology for microbial carbon chain elongation-derived MCCAs is still a critical bottleneck. Among various separation technologies, liquid-liquid extraction stands out with its significant advantages, demonstrating considerable potential for in situ extraction and purification of MCCAs. This review begins with the metabolic pathway of microbial carbon chain elongation for MCCAs synthesis. Through a comparative analysis of several in-situ separation technologies for MCCAs, it systematically reviews the technical principles, process parameters, key influencing factors, and bottlenecks in scale-up application of liquid-liquid in-situ extraction of MCCAs. In the future, the large-scale application of MCCAs production technology can be facilitated through innovations in extractant formulations and digital upgrades to online extraction processes, thereby contributing to the achievement of the “dual carbon” goal.

Key words: medium chain carboxylic acids, microbial carbon chain elongation, waste biomass, liquid-liquid extraction, in situ extraction

WANG Ting, XU Shao-qin, MING Ting-hong, XU Jia-jie. Research Progress in Liquid-liquid Extraction Technology for In Situ Extraction of Medium Chain Carboxylic Acids[J]. Biotechnology Bulletin, 2026, 42(7): 81-96.

Figures/Tables 8

References 82

[1]	Zhao JH, Ma HZ, Gao M, et al. Advancements in medium chain fatty acids production through chain elongation: Key mechanisms and innovative solutions for overcoming rate-limiting steps [J]. Bioresour Technol, 2024, 408: 131133.
[2]	石川, 刘越, 马金元, 等. 碳链延长技术在有机资源回收领域的研究进展 [J]. 中国环境科学, 2020, 40(10): 4439-4448.
	Shi C, Liu Y, Ma JY, et al. Review on research progress of anaerobic microbial chain elongation in organic waste treatment [J]. China Environ Sci, 2020, 40(10): 4439-4448.
[3]	Angenent LT, Richter H, Buckel W, et al. Chain elongation with reactor microbiomes: open-culture biotechnology to produce biochemicals [J]. Environ Sci Technol, 2016, 50(6): 2796-2810.
[4]	吴清莲, 邓琳, 任韦同, 等. 微生物碳链延长技术转化废弃生物质合成中链脂肪酸 [J]. 环境工程学报, 2023, 17(7): 2099-2108.
	Wu QL, Deng L, Ren WT, et al. Medium chain fatty acids biosynthesis from waste biomass by microbial chain elongation technology [J]. Chin J Environ Eng, 2023, 17(7): 2099-2108.
[5]	De Groof V, Coma M, Arnot T, et al. Medium chain carboxylic acids from complex organic feedstocks by mixed culture fermentation [J]. Molecules, 2019, 24(3): 398.
[6]	Menon A, Lyng JG. Circular bioeconomy solutions: driving anaerobic digestion of waste streams towards production of high value medium chain fatty acids [J]. Rev Environ Sci Biotechnol, 2021, 20(1): 189-208.
[7]	Kucek LA, Xu JJ, Nguyen M, et al. Waste conversion into n-caprylate and n-caproate: resource recovery from wine lees using anaerobic reactor microbiomes and in-line extraction [J]. Front Microbiol, 2016, 7: 1892.
[8]	Bian B, Bajracharya S, Xu JJ, et al. Microbial electrosynthesis from CO₂: Challenges, opportunities and perspectives in the context of circular bioeconomy [J]. Bioresour Technol, 2020, 302: 122863.
[9]	Shi XD, Wu L, Wei W, et al. Insights into the microbiomes for medium-chain carboxylic acids production from biowastes through chain elongation [J]. Crit Rev Environ Sci Technol, 2022, 52(21): 3787-3812.
[10]	Li J, Luo X, Liu H, et al. Carbon chain elongation microorganism stimulates caproate production from ethanol and acetate under applied voltage regulation [J]. Front Microbiol, 2025, 16: 1597990.
[11]	Jeon BS, Choi O, Um Y, et al. Production of medium-chain carboxylic acids by Megasphaera sp. MH with supplemental electron acceptors [J]. Biotechnol Biofuels, 2016, 9: 129.
[12]	Gao M, Lin YJ, Wang P, et al. Production of medium-chain fatty acid caproate from Chinese liquor distillers’ grain using pit mud as the fermentation microbes [J]. J Hazard Mater, 2021, 417: 126037.
[13]	Zhang WQ, Wang SL, Yin FB, et al. Medium-chain carboxylates production from co-fermentation of swine manure and corn stalk silage via lactic acid: Without external electron donors [J]. Chem Eng J, 2022, 439: 135751.
[14]	Zhang WQ, Yin FB, Dong HM, et al. Bioconversion of swine manure into high-value products of medium chain fatty acids [J]. Waste Manag, 2020, 113: 478-487.
[15]	Zhu XY, Zhou Y, Wang Y, et al. Production of high-concentration n-caproic acid from lactate through fermentation using a newly isolated Ruminococcaceae bacterium CPB6 [J]. Biotechnol Biofuels, 2017, 10: 102.
[16]	Ren WT, He ZL, Lv Y, et al. Carbon chain elongation characterizations of electrode-biofilm microbes in electro-fermentation [J]. Water Res, 2024, 267: 122417.
[17]	Wu QL, Bao X, Guo WQ, et al. Medium chain carboxylic acids production from waste biomass: Current advances and perspectives [J]. Biotechnol Adv, 2019, 37(5): 599-615.
[18]	Steen EJ, Kang YS, Bokinsky G, et al. Microbial production of fatty-acid-derived fuels and chemicals from plant biomass [J]. Nature, 2010, 463(7280): 559-562.
[19]	de Araújo Cavalcante W, Leitão RC, Gehring TA, et al. Anaerobic fermentation for n-caproic acid production: a review [J]. Process Biochem, 2017, 54: 106-119.
[20]	Liu C, Yin Y, Chen C, et al. Advances in electricity-steering organic waste bio-valorization for medium chain carboxylic acids production [J]. Energies, 2023, 16(6): 2571.
[21]	何子琳, 任韦同, 吴清莲, 等. 有机固废生物转化制备高附加值中链脂肪酸研究进展 [J]. 能源环境保护, 2024, 38(5): 45-57.
	He ZL, Ren WT, Wu QL, et al. Advances in bioconversion of organic solid wastes for the preparationof high-value medium-chain fatty acids [J]. Energy Environ Prot, 2024, 38(5): 45-57.
[22]	禹伟, 高教琪, 周雍进. 一碳生物转化合成有机酸的研究进展 [J]. 合成生物学, 2024, 5(5): 1169-1188.
	Yu W, Gao JQ, Zhou YJ. Bioconversion of one carbon feedstocks for producing organic acids [J]. Synth Biol J, 2024, 5(5): 1169-1188.
[23]	王玉洁, 仇俊杰, 吕凡, 等. 乳酸介导碳链延长产己酸规模化应用瓶颈 [J]. 环境卫生工程, 2025, 33(3): 27-36, 48.
	Wang YJ, Qiu JJ, Lyu F, et al. Bottlenecks in scaling up lactate-mediated carbon chain elongation for caproate production [J]. Environ Sanit Eng, 2025, 33(3): 27-36, 48.
[24]	Cheng MH, Qu GF, Xu R, et al. Research on the conversion of biowaste to MCCAs: a review of recent advances in the electrochemical synergistic anaerobic pathway [J]. Chemosphere, 2024, 366: 143430.
[25]	Yu JN, Liao JL, Huang ZX, et al. Enhanced anaerobic mixed culture fermentation with anion-exchange resin for caproate production [J]. Processes, 2019, 7(7): 404.
[26]	Vertova A, Aricci G, Rondinini S, et al. Electrodialytic recovery of light carboxylic acids from industrial aqueous wastes [J]. J Appl Electrochem, 2009, 39(11): 2051-2059.
[27]	Ge SJ, Usack JG, Spirito CM, et al. Long-term n-caproic acid production from yeast-fermentation beer in an anaerobic bioreactor with continuous product extraction [J]. Environ Sci Technol, 2015, 49(13): 8012-8021.
[28]	Carvajal-Arroyo JM, Andersen SJ, Ganigué R, et al. Production and extraction of medium chain carboxylic acids at a semi-pilot scale [J]. Chem Eng J, 2021, 416: 127886.
[29]	Xu JJ, Hao JX, Guzman JJL, et al. Temperature-phased conversion of acid whey waste into medium-chain carboxylic acids via lactic acid: No external e-donor [J]. Joule, 2019, 3(3): 885-888.
[30]	Andersen SJ, Candry P, Basadre T, et al. Electrolytic extraction drives volatile fatty acid chain elongation through lactic acid and replaces chemical pH control in thin stillage fermentation [J]. Biotechnol Biofuels, 2015, 8: 221.
[31]	Hernandez PA, Zhou MM, Vassilev I, et al. Selective extraction of medium-chain carboxylic acids by electrodialysis and phase separation [J]. ACS Omega, 2021, 6(11): 7841-7850.
[32]	Xu JJ, Guzman JJL, Angenent LT. Direct medium-chain carboxylic acid oil separation from a bioreactor by an electrodialysis/phase separation cell [J]. Environ Sci Technol, 2021, 55(1): 634-644.
[33]	Aghapour Aktij S, Zirehpour A, Mollahosseini A, et al. Feasibility of membrane processes for the recovery and purification of bio-based volatile fatty acids: a comprehensive review [J]. J Ind Eng Chem, 2020, 81: 24-40.
[34]	McDowall SC, Braune M, Nitzsche R. Recovery of bio-based medium-chain fatty acids with membrane filtration [J]. Sep Purif Technol, 2022, 286: 120430.
[35]	De Sitter K, Garcia-Gonzalez L, Matassa C, et al. The use of membrane based reactive extraction for the recovery of carboxylic acids from thin stillage [J]. Sep Purif Technol, 2018, 206: 177-185.
[36]	Wang JL, Yin YN. Biological production of medium-chain carboxylates through chain elongation: an overview [J]. Biotechnol Adv, 2022, 55: 107882.
[37]	Elhami V, Antunes EC, Temmink H, et al. Recovery techniques enabling circular chemistry from wastewater [J]. Molecules, 2022, 27(4): 1389.
[38]	López-Garzón CS, Straathof AJJ. Recovery of carboxylic acids produced by fermentation [J]. Biotechnol Adv, 2014, 32(5): 873-904.
[39]	Beschkov VN. Ion exchange in downstream processing in biotechnology [J]. Phys Sci Rev, 2020, 5(7): 1-11.
[40]	Fernando-Foncillas C, Cabrera-Rodríguez CI, Caparrós-Salvador F, et al. Highly selective recovery of medium chain carboxylates from co-fermented organic wastes using anion exchange with carbon dioxide expanded methanol desorption [J]. Bioresour Technol, 2021, 319: 124178.
[41]	Taiwo KJ, Nguyen H, Usack JG. Continuous liquid-liquid extraction of medium-chain fatty acids from fermentation broth using hollow-fiber membranes [J]. JoVE, 2024, (210): 1-17.
[42]	Gadekar-Shinde S, Bhashkar Kumar R, Gaikwad S. Reactive extraction of caproic acid using tri n-octylamine+2 octanol system [J]. Mater Today Proc, 2023, 72: 260-267.
[43]	Bokhary A, Leitch M, Liao BQ. Liquid-liquid extraction technology for resource recovery: Applications, potential, and perspectives [J]. J Water Process Eng, 2021, 40: 101762.
[44]	Wasewar KL, Shende DZ. Reactive extraction of caproic acid using tri-n-butyl phosphate in hexanol, octanol, and decanol [J]. J Chem Eng Data, 2011, 56(2): 288-297.
[45]	Khasanov VV, Makarycheva AI, Slizhov YG. Determination of trace amounts of aliphatic acids in natural waters using liquid-liquid extraction [J]. J Anal Chem, 2020, 75(2): 161-166.
[46]	Mukherjee S, Munshi B. Experimental and theoretical analysis of reactive extraction of caproic acid by using TBP in green diluents [J]. Chem Eng Process Process Intensif, 2020, 153: 107926.
[47]	Saboe PO, Manker LP, Michener WE, et al. In situ recovery of bio-based carboxylic acids [J]. Green Chem, 2018, 20(8): 1791-1804.
[48]	Van Hecke W, Kaur G, De Wever H. Advances in in-situ product recovery (ISPR) in whole cell biotechnology during the last decade [J]. Biotechnol Adv, 2014, 32(7): 1245-1255.
[49]	Gössi A, Burgener F, Kohler D, et al. In-situ recovery of carboxylic acids from fermentation broths through membrane supported reactive extraction using membrane modules with improved stability [J]. Sep Purif Technol, 2020, 241: 116694.
[50]	Wasewar KL, Shende DZ. Equilibrium study for reactive extraction of caproic acid in mibk and xylene [J]. Engineering, 2011, 3(8): 829-835.
[51]	Mishra P. Reactive extraction of caproic acid using mixed tertiary extractant in non-toxic diluents [J]. Int J Res Appl Sci Eng Technol, 2019, 7(10): 82-86.
[52]	Datta D, Kumar S, Uslu H. Status of the reactive extraction as a method of separation [J]. J Chem, 2015, 2015: 853789.
[53]	Sprakel LMJ, Schuur B. Solvent developments for liquid-liquid extraction of carboxylic acids in perspective [J]. Sep Purif Technol, 2019, 211: 935-957.
[54]	Contreras-Dávila CA, Zuidema N, Buisman CJN, et al. Reactor microbiome enriches vegetable oil with n-caproate and n-caprylate for potential functionalized feed additive production via extractive lactate-based chain elongation [J]. Biotechnol Biofuels, 2021, 14(1): 232.
[55]	Yuan BM, Braune M, Gröngröft A. Liquid-liquid extraction of caproic and caprylic acid: solvent properties and pH [J]. Chem Ing Tech, 2023, 95(10): 1573-1579.
[56]	Choi K, Jeon BS, Kim BC, et al. In situ biphasic extractive fermentation for hexanoic acid production from sucrose by Megasphaera elsdenii NCIMB 702410 [J]. Appl Biochem Biotechnol, 2013, 171(5): 1094-1107.
[57]	Santos AG, de Albuquerque TL, Ribeiro BD, et al. In situ product recovery techniques aiming to obtain biotechnological products: a glance to current knowledge [J]. Biotech And App Biochem, 2021, 68(5): 1044-1057.
[58]	Wasewar KL, Shende DZ. Extraction of caproic acid using tri-n-butyl phosphate in benzene and toluene at 301 K [J]. J Chem Eng Data, 2010, 55(9): 4121-4125.
[59]	Gildemyn S, Molitor B, Usack JG, et al. Upgrading syngas fermentation effluent using Clostridium kluyveri in a continuous fermentation [J]. Biotechnol Biofuels, 2017, 10: 83.
[60]	Kumar S, Pandey S, Wasewar KL, et al. Reactive extraction as an intensifying approach for the recovery of organic acids from aqueous solution: a comprehensive review on experimental and theoretical studies [J]. J Chem Eng Data, 2021, 66(4): 1557-1573.
[61]	Cho EJ, Trinh LTP, Song Y, et al. Bioconversion of biomass waste into high value chemicals [J]. Bioresour Technol, 2020, 298: 122386.
[62]	Fernández-Blanco C, Sabbe K, Veiga MC, et al. Characterization of solvents and extractants for selective recovery of n-caproic acid [J]. Sep Purif Technol, 2025, 361: 131411.
[63]	Tönjes S, Uitterhaegen E, De Winter K, et al. Reactive extraction technologies for organic acids in industrial fermentation processes-A review [J]. Sep Purif Technol, 2025, 356: 129881.
[64]	Agler MT, Spirito CM, Usack JG, et al. Chain elongation with reactor microbiomes: upgrading dilute ethanol to medium-chain carboxylates [J]. Energy Environ Sci, 2012, 5(8): 8189.
[65]	Xu JJ, Guzman JJL, Andersen SJ, et al. In-line and selective phase separation of medium-chain carboxylic acids using membrane electrolysis [J]. Chem Commun, 2015, 51(31): 6847-6850.
[66]	Fu HX, Sun YQ, Teng H, et al. Salting-out extraction of carboxylic acids [J]. Sep Purif Technol, 2015, 139: 36-42.
[67]	Yesil H, Taner H, Ugur Nigiz F, et al. Pervaporative separation of mixed volatile fatty acids: a study towards integrated VFA production and separation [J]. Waste Biomass Valor, 2020, 11(5): 1737-1753.
[68]	Villegas-Rodríguez SB, Arreola-Vargas J, Buitrón G. Influence of pH and temperature on the performance and microbial community during the production of medium-chain carboxylic acids using winery effluents as substrate [J]. Environ Sci Pollut Res, 2025, 32(28): 16617-16626.
[69]	Gehring TA, Cavalcante WA, Colares AS, et al. Optimal pH set point for simultaneous production and pertraction of n-caproic acid: an experimental and simulation study [J]. J Chemical Tech & Biotech, 2020, 95(12): 3105-3116.
[70]	Marti ME. Solvent modification effect on the physical and chemical extraction of acetic acid [J]. Sep Sci Technol, 2016, 51(11): 1806-1816.
[71]	Kaur G, Garcia-Gonzalez L, Elst K, et al. Reactive extraction for in-situ carboxylate recovery from mixed culture fermentation [J]. Biochem Eng J, 2020, 160: 107641.
[72]	Blaga AC, Tucaliuc A, Kloetzer L. Applications of ionic liquids in carboxylic acids separation [J]. Membranes, 2022, 12(8): 771.
[73]	Urban C, Xu JJ, Sträuber H, et al. Production of drop-in fuels from biomass at high selectivity by combined microbial and electrochemical conversion [J]. Energy Environ Sci, 2017, 10(10): 2231-2244.
[74]	Xu JJ, Bian B, Angenent LT, et al. Long-term continuous extraction of medium-chain carboxylates by pertraction with submerged hollow-fiber membranes [J]. Front Bioeng Biotechnol, 2021, 9: 726946.
[75]	Chen YA, Saboe PO, Kruger JS, et al. Liquid-liquid extraction for in situ carboxylic acid recovery via continuous membrane-based emulsion separations [J]. Green Chem, 2024, 26(17): 9398-9414.
[76]	Wasewar KL. Reactive extraction: an intensifying approach for carboxylic acid separation [J]. Int J Chem Eng Appl, 2012: 249-255.
[77]	De Brabander P, Uitterhaegen E, Verhoeven E, et al. In situ product recovery of bio-based industrial platform chemicals: a guideline to solvent selection [J]. Fermentation, 2021, 7(1): 26.
[78]	Marták J, Rosenberg M, Schlosser Š, et al. Toxicity of organic solvents used in situ in microbial fermentation [J]. Biotechnol Tech, 1995, 9(4): 247-252.
[79]	Wu QL, Jiang Y, Chen Y, et al. Opportunities and challenges in microbial medium chain fatty acids production from waste biomass [J]. Bioresour Technol, 2021, 340: 125633.
[80]	房立霞, 冯雪茹, 刘夺, 等. 大肠杆菌合成中链脂肪酸研究进展 [J]. 科学通报, 2022, 67(25): 3014-3023.
	Fang LX, Feng XR, Liu D, et al. Advances on medium-chain fatty acids synthesis in Escherichia coli [J]. Chin Sci Bull, 2022, 67(25): 3014-3023.
[81]	Gu X, Sun J, Wang T, et al. Comprehensive review of microbial production of medium-chain fatty acids from waste activated sludge and enhancement strategy [J]. Bioresour Technol, 2024, 402: 130782.
[82]	Prat D, Wells A, Hayler J, et al. CHEM21 selection guide of classical- and less classical-solvents [J]. Green Chem, 2016, 18(1): 288-296.

类别 Category	化合物 Compound	碳原子数 Number of carbon atoms	溶解度 Solubility （mg/L） ^a	电子密度 Electron density （g COD/g） ^b	酸度系数 Acidity coefficient （pKa）
短链羧酸	乙酸	2	互溶	1.07	4.76
	丙酸	3	互溶	1.51	4.88
	丁酸	4	60 000	1.82	4.82
	戊酸	5	24 000	2.04	4.84
中链羧酸	己酸	6	10 300	2.20	4.80
	庚酸	7	2 820	2.34	4.80
	辛酸	8	735 ^c	2.44	4.89
	壬酸	9	284 ^d	2.53	4.95
	癸酸	10	62	2.60	4.90
	十一烷酸	11	52	2.66	4.95
	月桂酸	12	4.8	2.72	5.30

类别 Category	化合物 Compound	碳原子数 Number of carbon atoms	溶解度 Solubility （mg/L） ^a	电子密度 Electron density （g COD/g） ^b	酸度系数 Acidity coefficient （pKa）
短链羧酸	乙酸	2	互溶	1.07	4.76
	丙酸	3	互溶	1.51	4.88
	丁酸	4	60 000	1.82	4.82
	戊酸	5	24 000	2.04	4.84
中链羧酸	己酸	6	10 300	2.20	4.80
	庚酸	7	2 820	2.34	4.80
	辛酸	8	735 ^c	2.44	4.89
	壬酸	9	284 ^d	2.53	4.95
	癸酸	10	62	2.60	4.90
	十一烷酸	11	52	2.66	4.95
	月桂酸	12	4.8	2.72	5.30

类别 Category	萃取机理 Extraction mechanism	代表性萃取剂 Representative extractant	萃取的羧酸 Extracted carboxylic acids	参考文献 Reference
非极性萃取剂	主要通过范德华力与MCCAs分子发生疏水性缔合	正己烷	己酸	［45］
磷基萃取剂	通过磷氧基（P=O）上的孤对电子与MCCAs的羧基形成配位键或氢键	磷酸三丁酯（TBP）	己酸	［46］
		三辛基氧膦（TOPO）	乙酸、丁酸、丙酸、己酸、辛酸	［47-49］
		Cyanex 923	己酸、辛酸	［47， 49］
胺基萃取剂	与MCCAs形成氢键或离子对（酸碱反应）	三辛胺（TOA）	己酸、辛酸	［47］
		Aliquat 336	己酸	［50］
		三月桂胺（TDA）、三己胺（THA）、三丙胺（TPA）、三辛胺（TOA）	己酸	［51］

类别 Category	萃取机理 Extraction mechanism	代表性萃取剂 Representative extractant	萃取的羧酸 Extracted carboxylic acids	参考文献 Reference
非极性萃取剂	主要通过范德华力与MCCAs分子发生疏水性缔合	正己烷	己酸	［45］
磷基萃取剂	通过磷氧基（P=O）上的孤对电子与MCCAs的羧基形成配位键或氢键	磷酸三丁酯（TBP）	己酸	［46］
		三辛基氧膦（TOPO）	乙酸、丁酸、丙酸、己酸、辛酸	［47-49］
		Cyanex 923	己酸、辛酸	［47， 49］
胺基萃取剂	与MCCAs形成氢键或离子对（酸碱反应）	三辛胺（TOA）	己酸、辛酸	［47］
		Aliquat 336	己酸	［50］
		三月桂胺（TDA）、三己胺（THA）、三丙胺（TPA）、三辛胺（TOA）	己酸	［51］
