Cloning and Functional Characterization of HvNAC53 from Hulless Barley

doi:10.13560/j.cnki.biotech.bull.1985.2026-0002

Abstract

Abstract:

Objective NAC (NAM/ATAF1/2/CUC2) transcription factors are a crucial class of regulatory proteins in plants, extensively involved in growth, development, and responses to biotic and abiotic stresses. This study aimed to clone the HvNAC53 gene from hulless barley (Hordeum vulgare var. nudum), analyze its sequence characteristics and expression patterns, and functionally characterize it, thereby providing a theoretical basis for stress-tolerant molecular breeding in hulless barley. Methods The HvNAC53 gene was cloned from the hulless barley cultivar ‘Kunlun 14’. Bioinformatics analysis and RT-qPCR were used to analyze gene expression and protein characteristics. The role of HvNAC53 in response to low-temperature and drought stress was investigated through heterologous overexpression in Arabidopsis thaliana. Results The open reading frame of HvNAC53 is 1 550 bp in length, encoding a protein of 305 amino acids. The protein lacks transmembrane domains and signal peptides and is classified as a hydrophilic, unstable protein. Multiple cis-acting elements responsive to light, hormones, and stress were identified in the promoter region of HvNAC53. Phylogenetic analysis indicated that HvNAC53 is most closely related to TeNAC53 from Thinopyrum elongatum (tall wheatgrass). RT-qPCR results revealed high expression levels of HvNAC53 in roots and leaves compared to other tissues, and its expression was significantly induced by drought and cold stress. Subcellular localization demonstrated that HvNAC53 is localized in the nucleus. Furthermore, Arabidopsis thaliana lines heterologously overexpressing HvNAC53 exhibited significantly higher cold and drought tolerance than wild-type plants. Conclusion HvNAC53 positively regulates low-temperature and drought stress responses in hulless barley.

Key words: hulless barley, HvNAC53, low temperature, drought, heterologous overexpression, subcellular localization

HE Jing-jing, PENG Mao-la-zhuan, YAO Xiao-hua, YAO You-hua, WU Kun-lun, CUI Yong-mei. Cloning and Functional Characterization of HvNAC53 from Hulless Barley[J]. Biotechnology Bulletin, doi: 10.13560/j.cnki.biotech.bull.1985.2026-0002.

Figures/Tables 7

References 41

[1]	Mohanta TK, Yadav D, Khan A, et al. Genomics, molecular and evolutionary perspective of NAC transcription factors [J]. PLoS One, 2020, 15(4): e0231425.
[2]	Xiong HY, He HD, Chang Y, et al. Multiple roles of NAC transcription factors in plant development and stress responses [J]. J Integr Plant Biol, 2025, 67(3): 510-538.
[3]	Li WH, Li HW, Wei YF, et al. Overexpression of a Fragaria vesca NAM ATAF and CUC (NAC) transcription factor gene (FvNAC29) increases salt and cold tolerance in Arabidopsis thaliana [J]. Int J Mol Sci, 2024, 25(7): 4088.
[4]	孙欣, 上官凌飞, 房经贵, 等. 葡萄NAC转录因子家族生物信息学分析 [J]. 基因组学与应用生物学, 2011, 30(2): 229-242.
	Sun X, Shangguan LF, Fang JG, et al. Bioinformatics analysis of the NAC transcription factor family in grapevine [J]. Genom Appl Biol, 2011, 30(2): 229-242.
[5]	李圣龙, 王传铭, 李晓静. 石榴NAC转录因子家族的生物信息学分析 [J]. 分子植物育种, 2021, 19(1): 88-99.
	Li SL, Wang CM, Li XJ. Bioinformatic analysis of the NAC transcription factor family in Punica granatum L [J]. Mol Plant Breed, 2021, 19(1): 88-99.
[6]	代梦媛, 高梅, 李文昌. 蓖麻NAC转录因子家族的鉴定及生物信息学分析 [J]. 分子植物育种, 2020, 18(6): 1808-1817.
	Dai MY, Gao M, Li WC. Identification and bioinformatics analysis of NAC transcription factor family in castor bean [J]. Mol Plant Breed, 2020, 18(6): 1808-1817.
[7]	Wang GR, Yuan Z, Zhang PY, et al. Genome-wide analysis of NAC transcription factor family in maize under drought stress and rewatering [J]. Physiol Mol Biol Plants, 2020, 26(4): 705-717.
[8]	Liu XW, wang T, Bartholomew E, et al. Comprehensive analysis of NAC transcription factors and their expression during fruit spine development in cucumber (Cucumis sativus L.) [J]. Hortic Res, 2018, 5: 31.
[9]	王晓菲, 高利盈, 刘宁, 等. 桃基因PpNAC的鉴定及其在不同发育时期的表达分析 [J]. 河南农业大学学报, 2024, 58(3): 412-423.
	Wang XF, Gao LY, Liu N, et al. Identification and expression analysis of PpNAC genes during different development stages of peach fruit [J]. J Henan Agric Univ, 2024, 58(3): 412-423.
[10]	曲硕, 刘芳, 孙浩文, 等. 大豆NAC转录因子生物信息学分析及GmNAC-1克隆和亚细胞定位 [J]. 大豆科学, 2024, 43(5): 523-538.
	Qu S, Liu F, Sun HW, et al. Bioinformatics analysis of soybean NAC transcription factor and cloning and subcellular localization of GmNAC-1 [J]. Soybean Sci, 2024, 43(5): 523-538.
[11]	Xu PP, Ma W, Hu JB, et al. The nitrate-inducible NAC transcription factor NAC056 controls nitrate assimilation and promotes lateral root growth in Arabidopsis thaliana [J]. PLoS Genet, 2022, 18(3): e1010090.
[12]	Lee MH, Jeon HS, Kim HG, et al. An Arabidopsis NAC transcription factor NAC4 promotes pathogen-induced cell death under negative regulation by microRNA164 [J]. New Phytol, 2017, 214(1): 343-360.
[13]	Gao F, Xiong AS, Peng RH, et al. OsNAC52, a rice NAC transcription factor, potentially responds to ABA and confers drought tolerance in transgenic plants [J]. Plant Cell Tiss Organ Cult, 2010, 100(3): 255-262.
[14]	Xu PP, Ma W, Feng HF, et al. The NAC056 transcription factor confers freezing tolerance by positively regulating expression of CBFs and NIA1 in Arabidopsis [J]. Plant Commun, 2024, 5(7): 100923.
[15]	魏婵, 姚晓华, 姚有华, 等. 青稞HvnRPS2基因克隆及其在条纹病胁迫下的表达分析 [J]. 西北植物学报, 2021, 41(12): 2021-2029.
	Wei C, Yao XH, Yao YH, et al. Isolation and expression analysis of HvnRPS2 in hulless barley under leaf stripe stress [J]. Acta Bot Boreali Occidentalia Sin, 2021, 41(12): 2021-2029.
[16]	王子傲, 田瑞, 崔永梅, 等. 青稞茉莉酸合成途径关键基因HvnAOC克隆、生物信息学和表达模式研究 [J]. 湖南农业科学, 2025(1): 1-8.
	Wang ZA, Tian R, Cui YM, et al. Cloning, bioinformatics analysis, and expression pattern analysis of HvnAOC, a key gene of jasmonic acid biosynthesis in hulless barley [J]. Hunan Agric Sci, 2025(1): 1-8.
[17]	徐瑶. 青稞和燕麦营养特性及血糖生成指数的研究 [D]. 兰州: 兰州理工大学, 2024.
	Xu Y. The research on the nutritional characteristics and glycemic index of highland barley and oats [D]. Lanzhou: Lanzhou University of Technology, 2024.
[18]	郝帅, 宋艳玲, 孙爽, 等. 气候变化对青藏高原青稞生产影响的研究综述 [J]. 中国农业气象, 2023, 44(5): 398-409.
	Hao S, Song YL, Sun S, et al. Review on the impacts of climate change on highland barley production in Tibet Plateau [J]. Chin J Agrometeorol, 2023, 44(5): 398-409.
[19]	强小林, 巴桑玉珍, 扎西罗布. 青藏高原区域青稞生产现状调研考察初报 [J]. 西藏农业科技, 2011, 33(1): 36-38.
	Qiang XL, Ba S, Zha X. Preliminary study of analysis on plateau area highland barley production in Qinghai-Tibet suggested countermeasure [J]. Tibet J Agric Sci, 2011, 33(1): 36-38.
[20]	Lin Z, Li Y, Zhang ZJ, et al. A RAF-SnRK2 kinase cascade mediates early osmotic stress signaling in higher plants [J]. Nat Commun, 2020, 11: 613.
[21]	李丽杰, 胥佳静, 吴雯霏, 等. 拟南芥葡萄糖磷酸变位酶(PGM)基因调控植株耐盐性的功能研究 [J]. 基因组学与应用生物学, 2023, 42(5): 471-480.
	Li LJ, Xu JJ, Wu WF, et al. Functional study on the regulation of salt tolerance by glucose-phosphate mutase (PGM) gene in Arabidopsis thaliana [J]. Genom Appl Biol, 2023, 42(5): 471-480.
[22]	Chang TL, Zhao Y, He HY, et al. Exogenous melatonin improves growth in hulless barley seedlings under cold stress by influencing the expression rhythms of circadian clock genes [J]. PeerJ, 2021, 9: e10740.
[23]	袁雷, 刘依兰. 基于GIS和气候-土地利用信息的西藏青稞种植适宜性区划 [J]. 中国农学通报, 2017, 33(17): 92-97.
	Yuan L, Liu YL. Suitability regionalization for highland barley in Tibet based on climate, land use information and GIS [J]. Chin Agric Sci Bull, 2017, 33(17): 92-97.
[24]	戴飞. 大麦耐低温种质资源筛选和耐性机理研究 [D]. 杭州: 浙江大学, 2009.
	Dai F. Studies on screening of barley genotypes with frost tolerance: physiological and genetic aspects [D]. Hangzhou: Zhejiang University, 2009.
[25]	李洁. 青稞苗期耐旱性状的关联分析和候选基因的筛选 [D]. 雅安: 四川农业大学, 2022.
	Li J. Association analysis of drought tolerance traits and screening of candidate genes at seedling stage of hulless barley [D]. Ya’an: Sichuan Agricultural University, 2022.
[26]	姚晓华, 王越, 安立昆, 等. 青稞HvtAGO1基因的克隆及其在条纹病胁迫下的表达 [J]. 西北植物学报, 2021, 41(1): 20-28.
	Yao XH, Wang Y, An LK, et al. Identification and expression analysis of HvtAGO1 gene in response to barley leaf stripe in Tibetan hulless barley [J]. Acta Bot Boreali Occidentalia Sin, 2021, 41(1): 20-28.
[27]	房安石, 阮成江, 张莞晨, 等. 沙棘不同发育期种子粒重和大小基因表达的qRT-PCR分析 [J]. 分子植物育种, 2019, 17(19): 6405-6409.
	Fang AS, Ruan CJ, Zhang WC, et al. Quantitative expression of genes involved in seed weight and size in developing sea buckthorn seeds by qRT-PCR analysis [J]. Mol Plant Breed, 2019, 17(19): 6405-6409.
[28]	卢敏. 玉米ZmSNAC1和高粱SbSNAC1基因的克隆与功能分析 [D]. 北京: 中国农业科学院, 2013.
	Lu M. Cloning and functional analysis of ZmSNACl in maize (Zea mays L.) and SbSNACl gene in sorghum [Sorghum bicolor (L.) moench] [D]. Beijing: Chinese Academy of Agricultural Sciences, 2013.
[29]	Nuruzzaman M, Manimekalai R, Sharoni AM, et al. Genome-wide analysis of NAC transcription factor family in rice [J]. Gene, 2010, 465(1/2): 30-44.
[30]	刘福根. 水稻NAC转录因子基因OsNAC071的表达及功能分析 [D]. 昆明: 云南农业大学, 2023.
	Liu FG. Expression and functional analysis of a NAC transcription factor gene OsNAC071 in rice [D]. Kunming: Yunnan Agricultural University, 2023.
[31]	Hu HH, Dai MQ, Yao JL, et al. Overexpressing a NAM, ATAF, and CUC (NAC) transcription factor enhances drought resistance and salt tolerance in rice [J]. Proc Natl Acad Sci U S A, 2006, 103(35): 12987-12992.
[32]	牛丽, 王勇胜, 王长杰, 等. 大麦NAC基因家族鉴定分析及HvNAC38的耐盐功能验证 [J]. 作物学报, 2026, 52(3): 688-707.
	Niu L, Wang YS, Wang CJ, et al. Identification and analysis of the NAC gene family in barley (Hordeum vulgare L.) and functional validation of HvNAC38 in salt tolerance [J]. Acta Agron Sin, 2026, 52(3): 688-707.
[33]	Jeong JS, Kim YS, Baek KH, et al. Root-specific expression of OsNAC10 improves drought tolerance and grain yield in rice under field drought conditions [J]. Plant Physiol, 2010, 153(1): 185-197.
[34]	Le DT, Nishiyama R, Watanabe Y, et al. Genome-wide survey and expression analysis of the plant-specific NAC transcription factor family in soybean during development and dehydration stress [J]. DNA Res, 2011, 18(4): 263-276.
[35]	Song SY, Chen Y, Chen J, et al. Physiological mechanisms underlying OsNAC5-dependent tolerance of rice plants to abiotic stress [J]. Planta, 2011, 234(2): 331-345.
[36]	Hong YB, Zhang HJ, Huang L, et al. Overexpression of a stress-responsive NAC transcription factor gene ONAC022 improves drought and salt tolerance in rice [J]. Front Plant Sci, 2016, 7: 4.
[37]	陈吉宝, 赵丽英, 毛新国, 等. 转PvP5CS1基因拟南芥植株对干旱和盐胁迫的反应 [J]. 作物学报, 2010, 36(1): 147-153.
	Chen JB, Zhao LY, Mao XG, et al. Response of PvP5CS1 transgenie Arabidopsis plants to drought-and salt-stress [J]. Acta Agron Sin, 2010, 36(1): 147-153.
[38]	Qiang ZQ, Zeng Z, Ma DF, et al. NAC transcription factor LpNAC22 positively regulates drought tolerance in perennial ryegrass [J]. Plant Cell Environ, 2025, 48(10): 7256-7270.
[39]	Wu ZX, Wang P. PcNAC25, a NAC transcription factor of Pugionium cornutum (L.) Gaertn conferring enhanced drought and salt stress tolerances in Arabidopsis [J]. Sci Rep, 2025, 15: 1501.
[40]	Meng XG, Kang Z, Wang JZ, et al. The SlMYC2-SlNAC90-SlNAC102 module mediates low-temperature stress responses in tomato by regulating jasmonic acid biosynthesis [J]. Plant Cell Environ, 2026, 49(2): 968-982.
[41]	Zhang HF, Pei YP, Zhu FL, et al. CaSnRK2.4-mediated phosphorylation of CaNAC035 regulates abscisic acid synthesis in pepper (Capsicum annuum L.) responding to cold stress [J]. Plant J, 2024, 117(5): 1377-1391.

元件 Site name	序列 Sequence	功能 Function	数量 Amount
Box 4	ATTAAT	参与光响应的保守 DNA 模块的一部分 Part of a conserved DNA module involved in light responsiveness	3
LTR	CCGAAA	参与低温响应性的顺式作用元件 Cis-acting element involved in low-temperature responsiveness	1
TATA-box	ATTATA；TATAA；TATA；TATAAA	启动子核心元件 Core promoter element	12
TGACG-motif	TGACG	参与MeJA反应性的顺式作用调节元件 Cis-acting regulatory element involved in the MeJA-responsiveness	3
GC-motif	CCCCCG	参与缺氧特异性诱导的增强子样元件 Enhancer-like element involved in anoxic specific inducibility	1
CGTCA-motif	CGTCA	参与MeJA反应性的顺式作用调节元件 Cis-acting regulatory element involved in the MeJA-responsiveness	3
A-box	CCGTCC	顺式作用调节元件 Cis-acting regulatory element	4
MBS	CAACTG	MYB结合位点参与干旱诱导 MYB binding site involved in drought-inducibility	3
I-box	gGATAAGGTG	光响应元件 Part of a light responsive element	1
G-box	CACGTC；TACGTG；CACGAC； GCCACGTGGA；CACGTG； ACACGTGT；TCCACATGGCA；	参与光响应的顺式作用调节元件 Cis-acting regulatory element involved in light responsiveness	18
GA-motif	ATAGATAA	光响应元件 Part of a light responsive element	1
LAMP-element	CCTTATCCA	光响应元件 Part of a light responsive element	1
TCA-element	CCATCTTTTT	参与水杨酸反应性的顺式作用元件 Cis-acting element involved in salicylic acid responsiveness	1
ABRE	ACGTG；CGTACGTGCA； CACGTG； GACACGTGGC； CGCACGTGTC	参与脱落酸反应的顺式作用元件 Cis-acting element involved in the abscisic acid responsiveness	15
CAAT-box	CCAAT；TGCCAAC；CAAAT	启动子和增强子区域中的常见顺式作用元件 Common cis-acting element in promoter and enhancer regions	6
MRE	AACCTAA	MYB结合位点参与光响应 MYB binding site involved in light responsiveness	1
ACE	GACACGTATG	参与光响应的顺式作用调节元件 Cis-acting element involved in light responsiveness	1

元件 Site name	序列 Sequence	功能 Function	数量 Amount
Box 4	ATTAAT	参与光响应的保守 DNA 模块的一部分 Part of a conserved DNA module involved in light responsiveness	3
LTR	CCGAAA	参与低温响应性的顺式作用元件 Cis-acting element involved in low-temperature responsiveness	1
TATA-box	ATTATA；TATAA；TATA；TATAAA	启动子核心元件 Core promoter element	12
TGACG-motif	TGACG	参与MeJA反应性的顺式作用调节元件 Cis-acting regulatory element involved in the MeJA-responsiveness	3
GC-motif	CCCCCG	参与缺氧特异性诱导的增强子样元件 Enhancer-like element involved in anoxic specific inducibility	1
CGTCA-motif	CGTCA	参与MeJA反应性的顺式作用调节元件 Cis-acting regulatory element involved in the MeJA-responsiveness	3
A-box	CCGTCC	顺式作用调节元件 Cis-acting regulatory element	4
MBS	CAACTG	MYB结合位点参与干旱诱导 MYB binding site involved in drought-inducibility	3
I-box	gGATAAGGTG	光响应元件 Part of a light responsive element	1
G-box	CACGTC；TACGTG；CACGAC； GCCACGTGGA；CACGTG； ACACGTGT；TCCACATGGCA；	参与光响应的顺式作用调节元件 Cis-acting regulatory element involved in light responsiveness	18
GA-motif	ATAGATAA	光响应元件 Part of a light responsive element	1
LAMP-element	CCTTATCCA	光响应元件 Part of a light responsive element	1
TCA-element	CCATCTTTTT	参与水杨酸反应性的顺式作用元件 Cis-acting element involved in salicylic acid responsiveness	1
ABRE	ACGTG；CGTACGTGCA； CACGTG； GACACGTGGC； CGCACGTGTC	参与脱落酸反应的顺式作用元件 Cis-acting element involved in the abscisic acid responsiveness	15
CAAT-box	CCAAT；TGCCAAC；CAAAT	启动子和增强子区域中的常见顺式作用元件 Common cis-acting element in promoter and enhancer regions	6
MRE	AACCTAA	MYB结合位点参与光响应 MYB binding site involved in light responsiveness	1
ACE	GACACGTATG	参与光响应的顺式作用调节元件 Cis-acting element involved in light responsiveness	1

蛋白名称 Protein name	注释 Annotation
M0XWR0_HORVV	含NAC结构域的蛋白
M0ZFS5_HORVV	WD_REPEATS_REGION含有结构域的蛋白质
A0A287LB51	EGF_CA含有结构域的蛋白质
A0A287IMF4	Ipi1_N含有结构域的蛋白质
F2DHF8_H0RVV	Pescadillo同源物；核糖体RNA成熟和大核糖体亚基形成所必需的
A0A287EA93	核糖体生物发生蛋白BOP1同源物；核糖体RNA成熟和大核糖体亚基形成所必需的；属于WD重复 BOP1/ERB1 家族
M0XXL5_HORVV	生长素反应因子
M0XAA8_HORVV	生长素反应因子
A0A287TNV8	生长素反应因子

蛋白名称 Protein name	注释 Annotation
M0XWR0_HORVV	含NAC结构域的蛋白
M0ZFS5_HORVV	WD_REPEATS_REGION含有结构域的蛋白质
A0A287LB51	EGF_CA含有结构域的蛋白质
A0A287IMF4	Ipi1_N含有结构域的蛋白质
F2DHF8_H0RVV	Pescadillo同源物；核糖体RNA成熟和大核糖体亚基形成所必需的
A0A287EA93	核糖体生物发生蛋白BOP1同源物；核糖体RNA成熟和大核糖体亚基形成所必需的；属于WD重复 BOP1/ERB1 家族
M0XXL5_HORVV	生长素反应因子
M0XAA8_HORVV	生长素反应因子
A0A287TNV8	生长素反应因子
