蒺藜苜蓿bZIP转录因子MtbZIP29的克隆及功能分析

doi:10.13560/j.cnki.biotech.bull.1985.2025-0482

摘要/Abstract

摘要：

目的克隆蒺藜苜蓿（Medicago truncatula）MtbZIP29基因，研究bZIP29转录因子转录自激活、亚细胞定位及表达特征等，为后续阐明MtbZIP29基因参与蒺藜苜蓿生长发育、内源激素信号转导提供一定的理论研究基础。方法从野生型苜蓿‘R108’中克隆MtbZIP29基因，构建试验所需的表达载体，通过瞬时表达融合蛋白观察其亚细胞定位，利用酵母表达分析其自激活活性；对MtbZIP29基因进行生物信息学分析，包括蛋白质理化性质、启动子顺式作用元件、蛋白质结构等；利用RT-qPCR方法对不同组织中及不同激素（ABA、SA、6-BA、IAA、MeJA）处理条件下的MtbZIP29进行表达分析；利用农杆菌介导法，获得转基因烟草植株，分析MtbZIP29的功能。结果成功克隆MtbZIP29基因，基因编码区全长1 518 bp，编码506个氨基酸，分子量55.830 kD，理论等电点为6.82，不稳定系数63.60，为不稳定亲水性蛋白；二级结构预测α螺旋占比25.89%，延伸链为0.59%，无规则卷曲为73.52%；亚细胞定位结果表明，该蛋白定位于细胞核；酵母实验表明，该基因编码蛋白具有转录自激活活性；表达特征分析显示，MtbZIP29基因在叶片中的表达水平最高，而茎和荚果中的表达水平明显低于其他组织，同时MtbZIP29基因的表达水平明显受到不同激素处理的影响。对转基因和野生型植株对比发现，转基因烟草的根系更加发达，同时根茎处具有明显的膨大。结论 MtbZIP29基因参与根系生长发育，对不同激素均有响应，可能通过整合激素信号参与植物根系形态建成及逆境适应性的调控过程。

关键词: 蒺藜苜蓿, MtbZIP29转录因子, 表达特征, 自激活, 细胞核定位, 烟草, 农杆菌转化, 启动子分析

Abstract:

Objective Clone the MtbZIP29 gene from Medicago truncatula to study the self-activation, subcellular localization, and expression characteristics of the bZIP29 transcription factor, providing a theoretical research foundation for elucidating the involvement of the MtbZIP29 gene in the growth and development of M. truncatula and endogenous hormone signaling transduction. Method The MtbZIP29 gene was cloned from the wild-type M. truncatula 'R108', and expression vectors were constructed for experimental purposes. Subcellular localization was observed using a transient fusion protein assay, and using yeast to analyze its self-activation activity. Bioinformatics analyses were conducted on the MtbZIP29 gene, including protein physicochemical property analysis, prediction of promoter cis-acting elements, and prediction of secondary and tertiary protein structures. Additionally, RT-qPCR was employed to analyze the expression patterns of MtbZIP29 across different tissues and under treatments with various hormones (ABA, SA, 6-BA, IAA, and MeJA). Transgenic tobacco plants were obtained using Agrobacterium-mediated method, and the function of MtbZIP29 was analyzed. Result The MtbZIP29 gene was successfully cloned, with a coding sequence (CDS) length of 1,518 bp encoding 506 amino acids. The encoded protein had molecular weight of 55.830 kD, a theoretical isoelectric point (pI) of 6.82, an instability index of 63.60, and is classified as an unstable hydrophilic protein. Secondary structure prediction revealed that α-helixes accounted for 25.89%, extended strands for 0.59%, and the remaining 73.52% as random coils. Subcellular localization indicated the protein was localized to the nucleus. Yeast assays demonstrated the encoded protein has transcriptional self-activation activity. Expression profiling showed that MtbZIP29 transcripts were the most abundant in the leaves, significantly lower in the stems and pods compared to other tissues and markedly influenced by different hormone treatments. Analysis of MtbZIP29-overexpressing plants showed that the rhizomes of transgenic tobacco were significantly enlarged compared with wild-type tobacco. Conclusion The MtbZIP29 gene is involved in root growth and development, responding to different hormones, and may participate in the regulatory processes of root morphology construction and stress adaptability by integrating hormone signals.

Key words: Medicago truncatula, MtbZIP transcription factor, expression pattern, self-activation, nuclear localization, tobacco, agrobacterium transformation, promoter analysis

张驰昊, 刘晋囡, 晁跃辉. 蒺藜苜蓿bZIP转录因子MtbZIP29的克隆及功能分析[J]. 生物技术通报, doi: 10.13560/j.cnki.biotech.bull.1985.2025-0482.

ZHANG Chi-hao, LIU Jin-nan, CHAO Yue-hui. Cloning and Functional Analysis of a bZIP Transcription Factor MtbZIP29 from Medicago truncatula[J]. Biotechnology Bulletin, doi: 10.13560/j.cnki.biotech.bull.1985.2025-0482.

图/表 10

参考文献 38

[1]	Weidemüller P, Kholmatov M, Petsalaki E, et al. Transcription factors: Bridge between cell signaling and gene regulation [J]. Proteomics, 2021, 21(23/24): 2000034.
[2]	Landschulz WH, Johnson PF, McKnight SL. The leucine zipper: a hypothetical structure common to a new class of DNA binding proteins [J]. Science, 1988, 240(4860): 1759-1764.
[3]	Zhang TT, Zhou Y. Plant transcription factors and salt stress [M]//Plant Transcription Factors. Academic Press, 2023: 369-381.
[4]	Kuravsky M, Grey G, Kelly C F, et al. A basic leucine zipper uses a dimer pathway to locate its targets in DNA mixtures[J]. bioRxiv, 2025: 2025.08. 25.672131.
[5]	Yu Y, Qian YC, Jiang MY, et al. Regulation mechanisms of plant basic leucine zippers to various abiotic stresses [J]. Front Plant Sci, 2020, 11: 1258.
[6]	Wang BX, Xu B, Liu Y, et al. A Novel mechanisms of the signaling cascade associated with the SAPK10-bZIP20-NHX1 synergistic interaction to enhance tolerance of plant to abiotic stress in rice (Oryza sativa L.) [J]. Plant Sci, 2022, 323: 111393.
[7]	Hussain Q, Asim M, Zhang R, et al. Transcription factors interact with ABA through gene expression and signaling pathways to mitigate drought and salinity stress [J]. Biomolecules, 2021, 11(8): 1159.
[8]	Yoshida T, Fujita Y, Sayama H, et al. AREB1, AREB2, and ABF₃ are master transcription factors that cooperatively regulate ABRE-dependent ABA signaling involved in drought stress tolerance and require ABA for full activation [J]. Plant J, 2010, 61(4): 672-685.
[9]	Manna M, Thakur T, Chirom O, et al. Transcription factors as key molecular target to strengthen the drought stress tolerance in plants [J]. Physiol Plant, 2021, 172(2): 847-868.
[10]	曹丽茹, 马晨晨, 庞芸芸, 等. 玉米bZIP转录因子ZmbZIP26的分子特征、亚细胞定位及响应非生物胁迫的表达分析 [J]. 华北农学报, 2023, 38(4): 1-10.
	Cao LR, Ma CC, Pang YY, et al. Molecular characteristics, subcellular localization and expression analysis of maize bZIP transcription factor ZmbZIP26 in response to abiotic stress [J]. Acta Agric Boreali Sin, 2023, 38(4): 1-10.
[11]	郭纯, 宋桂梅, 闫艳, 等. 西洋参bZIP基因家族全基因组鉴定和表达分析 [J]. 生物技术通报, 2024, 40(4): 167-178.
	Guo C, Song GM, Yan Y, et al. Genome wide identification and expression analysis of the bZIP gene family in Panax quinquefolius [J]. Biotechnol Bull, 2024, 40(4): 167-178.
[12]	Gai W-X, Ma X, Qiao Y-M, et al. Characterization of the bZIP transcription factor family in pepper (Capsicum annuum L.): CabZIP25 positively modulates the salt tolerance [J]. Front Plant Sci, 2020, 11: 139.
[13]	张蕾, 陈昕涛, 白丽娟, 等. 大豆bZIP转录因子基因GmbZIP33的克隆与功能分析 [J]. 大豆科学, 2023, 42(5): 524-531.
	Zhang L, Chen XT, Bai LJ, et al. Cloning and functional analysis of GmbZIP33 encoding bZIP transcription factor from soybean [J]. Soybean Sci, 2023, 42(5): 524-531.
[14]	Li MY, Hwarari D, Li Y, et al. The bZIP transcription factors in Liriodendron chinense: Genome-wide recognition, characteristics and cold stress response [J]. Front Plant Sci, 2022, 13: 1035627.
[15]	Hsieh TH, Li CW, Su RC, et al. A tomato bZIP transcription factor, SlAREB, is involved in water deficit and salt stress response [J]. Planta, 2010, 231(6): 1459-1473.
[16]	曾力旺, 张小燕, 林墁, 等. 木薯MebZIP27基因的克隆与原核表达分析 [J]. 福建农业学报, 2025, 40(1): 1-9.
	Zeng LW, Zhang XY, Lin M, et al. Cloning and prokaryotic expression analysis of cassava MebZIP27 gene [J]. Fujian J Agric Sci, 2025, 40(1): 1-9.
[17]	曹晓宇, 王学敏, 郭继承, 等. 紫花苜蓿bZIP转录因子MsbZIP1的克隆、表达特性和遗传转化分析 [J]. 草地学报, 2020, 28(3): 613-622.
	Cao XY, Wang XM, Guo JC, et al. Cloning, expression characteristics and genetic transformation analysis of a bZIP transcription factor MsbZIP1 in alfalfa [J]. Acta Agrestia Sin, 2020, 28(3): 613-622.
[18]	Liu SX, Qin B, Fang QX, et al. Genome-wide identification, phylogeny and expression analysis of the bZIP gene family in Alfalfa (Medicago sativa) [J]. Biotechnol Biotechnol Equip, 2021, 35(1): 905-916.
[19]	Zhao K, Chen S, Yao WJ, et al. Genome-wide analysis and expression profile of the bZIP gene family in poplar [J]. BMC Plant Biol, 2021, 21(1): 122.
[20]	Dash M, Yordanov YS, Georgieva T, et al. Poplar PtabZIP1-like enhances lateral root formation and biomass growth under drought stress [J]. Plant J, 2017, 89(4): 692-705.
[21]	赵安琪, 尹跃, 何军, 等. 枸杞LbaHY5基因克隆、亚细胞定位及表达分析 [J]. 华北农学报, 2024, 39(6): 76-83.
	Zhao AQ, Yin Y, He J, et al. Cloning, subcellular localization and expression analysis of LbaHY5 gene from Lycium barbarum [J]. Acta Agric Boreali Sin, 2024, 39(6): 76-83.
[22]	Yang SS, Zhang XX, Zhang XM, et al. A bZIP transcription factor, PqbZIP1, is involved in the plant defense response of American ginseng [J]. PeerJ, 2022, 10: e12939.
[23]	Niu XL, Fu DQ. The roles of BLH transcription factors in plant development and environmental response [J]. Int J Mol Sci, 2022, 23(7): 3731.
[24]	Verma S, Attuluri VPS, Robert HS. Transcriptional control of Arabidopsis seed development [J]. Planta, 2022, 255(4): 90.
[25]	Guo ZL, Dzinyela R, Yang LM, et al. bZIP transcription factors: structure, modification, abiotic stress responses and application in plant improvement [J]. Plants, 2024, 13(15): 2058.
[26]	Alonso-Blanco C, Aarts MGM, Bentsink L, et al. What has natural variation taught us about plant development, physiology, and adaptation? [J]. Plant Cell, 2009, 21(7): 1877-1896.
[27]	Li JS, Wang XM, Zhang YL, et al. cGMP regulates hydrogen peroxide accumulation in calcium-dependent salt resistance pathway in Arabidopsis thaliana roots [J]. Planta, 2011, 234(4): 709-722.
[28]	Kaur P, Lui C, Dudchenko O, et al. Delineating the Tnt1 insertion landscape of the model legume Medicago truncatula cv. R108 at the hi-C resolution using a chromosome-length genome assembly [J]. Int J Mol Sci, 2021, 22(9): 4326.
[29]	Livak KJ, Schmittgen TD. Analysis of relative gene expression data using real-time quantitative PCR and the 2-ΔΔCT method [J]. Methods, 2001, 25(4): 402-408.
[30]	Riechmann JL, Heard J, Martin G, et al. Arabidopsis Transcription factors: genome-wide comparative analysis among eukaryotes [J]. Science, 2000, 290(5499): 2105-2110.
[31]	Fujii H, Verslues PE, Zhu JK. Identification of two protein kinases required for abscisic acid regulation of seed germination, root growth, and gene expression in Arabidopsis [J]. Plant Cell, 2007, 19(2): 485-494.
[32]	Yoshida T, Fujita Y, Maruyama K, et al. Four Arabidopsis AREB/ABF transcription factors function predominantly in gene expression downstream of SnRK2 kinases in abscisic acid signalling in response to osmotic stress [J]. Plant Cell Environ, 2015, 38(1): 35-49.
[33]	Fujii H, Zhu JK. Arabidopsis mutant deficient in 3 abscisic acid-activated protein kinases reveals critical roles in growth, reproduction, and stress [J]. Proc Natl Acad Sci U S A, 2009, 106(20): 8380-8385.
[34]	Cutler SR, Rodriguez PL, Finkelstein RR, et al. Abscisic acid: emergence of a core signaling network [J]. Annu Rev Plant Biol, 2010, 61: 651-679.
[35]	Luang S, Sornaraj P, Bazanova N, et al. The wheat TabZIP2 transcription factor is activated by the nutrient starvation-responsive SnRK3/CIPK protein kinase [J]. Plant Mol Biol, 2018, 96(6): 543-561.
[36]	Han XY, Wei XP, Lu WJ, et al. Transcriptional regulation of KCS gene by bZIP29 and MYB70 transcription factors during ABA-stimulated wound suberization of kiwifruit (Actinidia deliciosa) [J]. BMC Plant Biol, 2022, 22(1): 23.
[37]	Zhang LN, Zhang LC, Xia C, et al. A novel wheat bZIP transcription factor, TabZIP60, confers multiple abiotic stress tolerances in transgenic Arabidopsis [J]. Physiol Plant, 2015, 153(4): 538-554.
[38]	Van Leene J, Blomme J, Kulkarni SR, et al. Functional characterization of the Arabidopsis transcription factor bZIP29 reveals its role in leaf and root development [J]. J Exp Bot, 2016, 67(19): 5825-5840.

引物名称 Primer name	序列 Sequence（5′-3′）	用途 Usage
MtbZIP29-F	GATAAGCGCCTGCTCCTT	克隆基因 Cloning gene
MtbZIP29-R	ACGACCTCCAATCCAACC
M13-47	CAGGGTTTTCCCAGTCACG
M13-48	GAGCGGATAACAATTTCACAC
3302-bZIP29-F	CATGGTAGATCTGACTAGTATGGAAGATACTGAAGCAGCTTCATCTTTCAAAATG	构建亚细胞定位载体 Construction of subcellular localization vector
3302-bZIP29-R	GGCCTCCTAGGTACACGCGTTTGCTTTAACTCATTCTTTGAGTTGGCATT	构建亚细胞定位载体 Construction of subcellular localization vector
BDbZIP29-F	TCAGAGGAGGACCTGCATATGGAAGATACTGAAGCAGCT	构建酵母表达载体 Construction of yeast expression vector
BD-bZIP29-R	CGCTGCAGGTCGACGGATCCCTATTGCTTTAACTCATTCTTTGAGTTG	构建酵母表达载体 Construction of yeast expression vector
BD-bZIP29-U-F	GCCATGGAGGCCGAATTCCCGATGGAAGATACTGAAGCAGC	构建酵母表达载体（N端） Construction of yeast expression vector （N-terminus）
BD-ZIP29-U-R	CTGCAGGTCGACGGATCCCCTTACACAACTTCACCTTCCGGCG
BD-bZIP29-D-F	GCCATGGAGGCCGAATTCCCGGATGATCTTTTTTCTGCTTA	构建酵母表达载体（C端） Construction of yeast expression vector （C-terminus）
BD-bZIP29-D-R	CTGCAGGTCGACGGATCCCCCTATTGCTTTAACTCATTCT
MtbZIP29 qRT-F	TGGGAATGGTGAGTTTAG	基因表达分析 Gene expression analysis
MtbZIP29 qRT-R	CAGAAAGTGTAGTGGCTTC	基因表达分析 Gene expression analysis
MtActin-F	TGATCTGGCTGGTCGTGACCTTA	蒺藜苜蓿内参基因表达分析 Expression analysis of Medicago truncatula internal reference gene
MtActin-R	ATGCCTGCTGCTTCCATTCCTAT
Nt-bZIP29-F	ATCAGATCCCGGTTTCAC	转基因烟草PCR检测 PCR analysis of transgenic tobacco
Nt-bZIP29-R	CTATCATCAGTAGCCGCGT	转基因烟草PCR检测 PCR analysis of transgenic tobacco

引物名称 Primer name	序列 Sequence（5′-3′）	用途 Usage
MtbZIP29-F	GATAAGCGCCTGCTCCTT	克隆基因 Cloning gene
MtbZIP29-R	ACGACCTCCAATCCAACC
M13-47	CAGGGTTTTCCCAGTCACG
M13-48	GAGCGGATAACAATTTCACAC
3302-bZIP29-F	CATGGTAGATCTGACTAGTATGGAAGATACTGAAGCAGCTTCATCTTTCAAAATG	构建亚细胞定位载体 Construction of subcellular localization vector
3302-bZIP29-R	GGCCTCCTAGGTACACGCGTTTGCTTTAACTCATTCTTTGAGTTGGCATT	构建亚细胞定位载体 Construction of subcellular localization vector
BDbZIP29-F	TCAGAGGAGGACCTGCATATGGAAGATACTGAAGCAGCT	构建酵母表达载体 Construction of yeast expression vector
BD-bZIP29-R	CGCTGCAGGTCGACGGATCCCTATTGCTTTAACTCATTCTTTGAGTTG	构建酵母表达载体 Construction of yeast expression vector
BD-bZIP29-U-F	GCCATGGAGGCCGAATTCCCGATGGAAGATACTGAAGCAGC	构建酵母表达载体（N端） Construction of yeast expression vector （N-terminus）
BD-ZIP29-U-R	CTGCAGGTCGACGGATCCCCTTACACAACTTCACCTTCCGGCG
BD-bZIP29-D-F	GCCATGGAGGCCGAATTCCCGGATGATCTTTTTTCTGCTTA	构建酵母表达载体（C端） Construction of yeast expression vector （C-terminus）
BD-bZIP29-D-R	CTGCAGGTCGACGGATCCCCCTATTGCTTTAACTCATTCT
MtbZIP29 qRT-F	TGGGAATGGTGAGTTTAG	基因表达分析 Gene expression analysis
MtbZIP29 qRT-R	CAGAAAGTGTAGTGGCTTC	基因表达分析 Gene expression analysis
MtActin-F	TGATCTGGCTGGTCGTGACCTTA	蒺藜苜蓿内参基因表达分析 Expression analysis of Medicago truncatula internal reference gene
MtActin-R	ATGCCTGCTGCTTCCATTCCTAT
Nt-bZIP29-F	ATCAGATCCCGGTTTCAC	转基因烟草PCR检测 PCR analysis of transgenic tobacco
Nt-bZIP29-R	CTATCATCAGTAGCCGCGT	转基因烟草PCR检测 PCR analysis of transgenic tobacco

用途 Usage	网址 Website
启动子及顺式作用元件预测 Promoter and cis-acting element prediction	PlantCARE， http：//bioinformatics.psb.ugent.be/webtools/plantcare/html
系统进化树分析 Phylogenetic tree analysis	NCBI， https：//www.ncbi.nlm.nih.gov/
蛋白质结构域分析 Protein structure domain analysis	UniProt， https：//www.uniprot.org/
蛋白质二级结构预测 Protein secondary structure prediction	SOPMA， https：//npsa.lyon.inserm.fr/cgibin/npsa_automat.pl page=/NPSA/npsa_sopma.html
蛋白质三级结构预测 Protein tertiary structure prediction	Swissmodel， https：//swissmodel.expasy.org/
蛋白质理化性质分析 Analysis of physicochemical properties of proteins	Expasy-ProtParam， http：//web.expasy.org/protparam Expasy-ProtScale， http：//web.expasy.org/protscale

用途 Usage	网址 Website
启动子及顺式作用元件预测 Promoter and cis-acting element prediction	PlantCARE， http：//bioinformatics.psb.ugent.be/webtools/plantcare/html
系统进化树分析 Phylogenetic tree analysis	NCBI， https：//www.ncbi.nlm.nih.gov/
蛋白质结构域分析 Protein structure domain analysis	UniProt， https：//www.uniprot.org/
蛋白质二级结构预测 Protein secondary structure prediction	SOPMA， https：//npsa.lyon.inserm.fr/cgibin/npsa_automat.pl page=/NPSA/npsa_sopma.html
蛋白质三级结构预测 Protein tertiary structure prediction	Swissmodel， https：//swissmodel.expasy.org/
蛋白质理化性质分析 Analysis of physicochemical properties of proteins	Expasy-ProtParam， http：//web.expasy.org/protparam Expasy-ProtScale， http：//web.expasy.org/protscale
