玉米根系原生质体制备及瞬时转化体系的建立

doi:10.13560/j.cnki.biotech.bull.1985.2026-0349

摘要/Abstract

摘要：

目的建立玉米根系原生质体的高效制备与瞬时转化方法，为玉米根系特异功能基因的研究提供技术支撑。方法以玉米自交系Mo17幼苗根系为材料，通过Box-Behnken响应面法，分别设计五因素三水平、三因素三水平试验，筛选原生质体制备（纤维素酶浓度、离析酶浓度、甘露醇浓度、酶解时间、根龄）与瞬时转化（质粒用量、PEG4000浓度、转化时间）的最优条件，测定不同组合下原生质体产量、活细胞比例及转化效率，并通过激素响应分析、亚细胞定位、Western-blot和双荧光素酶报告系统验证体系有效性。结果玉米根系原生质体制备的最优条件为2%纤维素酶、0.6%离析酶、0.6 mol/L甘露醇、酶解6 h、根龄9 d，此条件下原生质体产量达2.17×10⁶ cells/mL，活细胞率94.33%；瞬时转化的最优条件为每100 μL原生质体加10 μg质粒、PEG4000浓度40%、转化25 min，转化效率最高达65.1%。qPCR结果表明在原生质体中激素对其信号基因的激活作用与其在源组织中趋势一致；结合亚细胞定位、Western-blot及双荧光素酶报告实验验证，表明该体系可成功实现外源基因表达、蛋白亚细胞定位及转录调控分析。结论建立了玉米根系原生质体制备与瞬时转化体系，为玉米根系特异基因的功能解析及信号通路研究提供了高效可靠的技术手段。

关键词: 玉米, 根系, 原生质体, 瞬时转化体系, Box-Behnken响应面法

Abstract:

Objective This study aims to establish an efficient protoplast isolation and transient transformation system for maize roots, thereby providing technical support for studying maize root-specific functional genes. Method With roots of maize inbred line Mo17 seedlings as explants, Box-Behnken response surface method was used to design five-factor three-level and three-factor three-level experiments to optimize the conditions of protoplast isolation (cellulase concentration, macerozyme concentration, mannitol concentration, enzymatic hydrolysis time, root age) and transient transformation (plasmid dosage, PEG4000 concentration, transformation time), respectively. The protoplast yield, viable cell ratio and transformation efficiency under different condition combinations were evaluated. Furthermore, the system was verified by analysis in response to hormone treatment, subcellular localization, Western-blot and dual-luciferase reporter assays. Result The optimal isolation conditions were 2% cellulase, 0.6% macerozyme, 0.6 mol/L mannitol, 6 h enzymatic hydrolysis and 9-day-old roots, with a protoplast yield of 2.17×10⁶ cells/mL and a viable cell rate of 94.33%. The optimal transformation conditions were 10 μg plasmid per 100 μL protoplasts, 40% PEG4000 and 25 min transformation, achieving a maximum transformation efficiency of 65.1%. qPCR results showed that the activation of hormone-related genes by exogenous hormone treatment in protoplasts was consistent with that in the source tissues. Subsequent verification experiments proved that this system was successfully used for exogenous gene expression, protein subcellular localization and transcriptional regulation analysis. Conclusion This study established an efficient and reliable protoplast isolation and transient transformation system for maize roots, which offers a valuable technical tool for functional studies on maize root-specific genes.

Key words: maize, root, protoplast, transient transformation system, Box-Behnken response surface method

傅竞也, 燕杰, 裴文争, 包福琨, 杨越, 王丽平, 王强. 玉米根系原生质体制备及瞬时转化体系的建立[J]. 生物技术通报, doi: 10.13560/j.cnki.biotech.bull.1985.2026-0349.

FU Jing-ye, YAN Jie, PEI Wen-zheng, BAO Fu-kun, YANG Yue, WANG Li-ping, WANG Qiang. Establishment of a Protocol for Isolation and Transient Transformation of Maize Root Protoplasts[J]. Biotechnology Bulletin, doi: 10.13560/j.cnki.biotech.bull.1985.2026-0349.

图/表 9

参考文献 31

[1]	Schiefelbein JW, Benfey PN. The development of plant roots: new approaches to underground problems [J]. Plant Cell, 1991, 3(11): 1147-1154.
[2]	Rogers ED, Benfey PN. Regulation of plant root system architecture: implications for crop advancement [J]. Curr Opin Biotechnol, 2015, 32: 93-98.
[3]	Topp CN, Bray AL, Ellis NA, et al. How can we harness quantitative genetic variation in crop root systems for agricultural improvement? [J]. J Integr Plant Biol, 2016, 58(3): 213-225.
[4]	Sheen J. Signal transduction in maize and Arabidopsis mesophyll protoplasts [J]. Plant Physiol, 2001, 127(4): 1466-1475.
[5]	Davey MR, Anthony P, Power JB, et al. Plant protoplasts: status and biotechnological perspectives [J]. Biotechnol Adv, 2005, 23(2): 131-171.
[6]	Wang N, Fan X, He MY, et al. Transcriptional repression of TaNOX10 by TaWRKY19 compromises ROS generation and enhances wheat susceptibility to stripe rust [J]. Plant Cell, 2022, 34(5): 1784-1803.
[7]	Wang G, Chen X, Yu CZ, et al. Release of a ubiquitin brake activates OsCERK1-triggered immunity in rice [J]. Nature, 2024, 629(8014): 1158-1164.
[8]	Fu JY, Pei WZ, He LQ, et al. ZmEREB92 plays a negative role in seed germination by regulating ethylene signaling and starch mobilization in maize [J]. PLoS Genet, 2023, 19(11): e1011052.
[9]	Zhuo MN, Sakuraba Y, Yanagisawa S. A jasmonate-activated MYC2-Dof2.1-MYC2 transcriptional loop promotes leaf senescence in Arabidopsis [J]. Plant Cell, 2020, 32(1): 242-262.
[10]	李婧瑶, 刘龙飚, 丁兵, 等. 植物原生质体分离及培养研究进展 [J]. 分子植物育种, 2023, 21(2): 620-632.
	Li JY, Liu LB, Ding B, et al. Research progress on isolation and culture of plant protoplasts [J]. Mol Plant Breed, 2023, 21(2): 620-632.
[11]	Gilliard G, Huby E, Cordelier S, et al. Protoplast: a valuable toolbox to investigate plant stress perception and response [J]. Front Plant Sci, 2021, 12: 749581.
[12]	吕仁瑶, 朱金洁, 刘昌林, 等. 玉米叶肉原生质体瞬时表达系统建立与优化 [J]. 玉米科学, 2023, 31(1): 32-39.
	Lü RY, Zhu JJ, Liu CL, et al. Establishment and optimization of a transient expression system for maize mesophyll protoplasts [J]. J Maize Sci, 2023, 31(1): 32-39.
[13]	Higa L, Blank M, Hampson E, et al. Rapid assessment of CRISPR gRNAs with optimized protoplast transformation in maize [J]. Plant Cell Rep, 2025, 44(10): 212.
[14]	Hu YF, Song DL, Gao L, et al. Optimization of isolation and transfection conditions of maize endosperm protoplasts [J]. Plant Meth, 2020, 16: 96.
[15]	Fu JY, Wang LP, Pei WZ, et al. ZmEREB92 interacts with ZmMYC2 to activate maize terpenoid phytoalexin biosynthesis upon Fusarium graminearum infection through jasmonic acid/ethylene signaling [J]. New Phytol, 2023, 237(4): 1302-1319.
[16]	Nguyen HT, Leipner J, Stamp P, et al. Low temperature stress in maize (Zea mays L.) induces genes involved in photosynthesis and signal transduction as studied by suppression subtractive hybridization [J]. Plant Physiol Biochem, 2009, 47(2): 116-122.
[17]	Ma HZ, Liu C, Li ZX, et al. ZmbZIP4 contributes to stress resistance in maize by regulating ABA synthesis and root development [J]. Plant Physiol, 2018, 178(2): 753-770.
[18]	Zhang YX, von Behrens I, Zimmermann R, et al. LATERAL ROOT PRIMORDIA 1 of maize acts as a transcriptional activator in auxin signalling downstream of the Aux/IAA gene rootless with undetectable meristem 1 [J]. J Exp Bot, 2015, 66(13): 3855-3863.
[19]	Xing HY, Pudake RN, Guo GG, et al. Genome-wide identification and expression profiling of auxin response factor (ARF) gene family in maize [J]. BMC Genom, 2011, 12: 178.
[20]	Fu JY, Liu Q, Wang C, et al. ZmWRKY79 positively regulates maize phytoalexin biosynthetic gene expression and is involved in stress response [J]. J Exp Bot, 2018, 69(3): 497-510.
[21]	Gulzar F, Fu JY, Zhu CY, et al. Maize WRKY transcription factor ZmWRKY79 positively regulates drought tolerance through elevating ABA biosynthesis [J]. Int J Mol Sci, 2021, 22(18): 10080.
[22]	孙鹤, 郎志宏, 朱莉, 等. 玉米、小麦、水稻原生质体制备条件优化 [J]. 生物工程学报, 2013, 29(2): 224-234.
	Sun H, Lang ZH, Zhu L, et al. Optimized condition for protoplast isolation from maize, wheat and rice leaves [J]. Chin J Biotechnol, 2013, 29(2): 224-234.
[23]	Yoo SD, Cho YH, Sheen J. Arabidopsis mesophyll protoplasts: a versatile cell system for transient gene expression analysis [J]. Nat Protoc, 2007, 2(7): 1565-1572.
[24]	Fu JY, Zhu L, Wang LY, et al. ZmWRKY29 transcriptionally represses ZmRBOHC to attenuate ROS production and facilitates Gibberella stalk rot susceptibility in maize [J]. Plant Biotechnol J, 2026, 24(6): 4044-4060.
[25]	Cosgrove DJ. Growth of the plant cell wall [J]. Nat Rev Mol Cell Biol, 2005, 6(11): 850-861.
[26]	Doblin MS, Kurek I, Jacob-Wilk D, et al. Cellulose biosynthesis in plants: from genes to rosettes [J]. Plant Cell Physiol, 2002, 43(12): 1407-1420.
[27]	李悦, 宋慧云, 王志, 等. 植物原生质体分离与瞬时表达体系研究进展 [J]. 植物生理学报, 2023, 59(1): 21-32.
	Li Y, Song HY, Wang Z, et al. Research progress of plant protoplast isolation and transient expression system [J]. Plant Physiol Commun, 2023, 59(1): 21-32.
[28]	杨成兰, 武雄雄, 祁存英, 等. 青稞叶片原生质体制备体系优化 [J]. 青海大学学报: 自然科学版, 2021, 39(4): 26-30.
	Yang CL, Wu XX, Qi CY, et al. Optimization of protoplast preparation system of Hordeum vulgare L. var. nudum. leaves [J]. J Qinghai Univ Nat Sci, 2021, 39(4): 26-30.
[29]	黄瑞华, 刘潇晗, 曹天丽, 等. 穿心莲叶片原生质体制备方法的建立与优化 [J]. 分子植物育种, 2021, 19(17): 5878-5885.
	Huang RH, Liu XH, Cao TL, et al. Optimization of protoplasts preparation of leaves from Andrographis paniculata (burm.f.) nees [J]. Mol Plant Breed, 2021, 19(17): 5878-5885.
[30]	Lazzeri PA. Stable transformation of barley via direct DNA uptake: electroporation- and PEG-mediated protoplast transformation [M]//Plant Gene Transfer and Expression Protocols. New Jersey Humana Press 2003: 95-106.
[31]	Jia Y, Peng G, Zhou Q. Establishment of an efficient protoplast-based base editing platform in lettuce [J]. Agronomy, 2026, 16(8): 776.

试验编号 Test No.	编码水平 Coded levels					实际水平 Actual levels					产量Yield ±SEM （×10⁶ cells/mL）	活细胞比例 FDA±SEM （%）
试验编号 Test No.	A	B	C	D	E	A	B	C	D	E	产量Yield ±SEM （×10⁶ cells/mL）	活细胞比例 FDA±SEM （%）
1	0	-1	0	1	0	1.5	0.4	0.6	8	7	1.65±0.21	90.62±0.77
2	0	0	0	0	0	1.5	0.6	0.6	6	7	1.46±0.14	87.12±1.39
3	-1	0	-1	0	0	1.0	0.6	0.4	6	7	1.52±0.08	88.16±0.96
4	0	0	0	-1	-1	1.5	0.6	0.6	4	5	1.81±0.06	90.31±1.21
5	1	0	-1	0	0	2.0	0.6	0.4	6	7	1.17±0.12	83.5±1.34
6	0	0	1	-1	0	1.5	0.6	0.8	4	7	1.08±0.13	89.2±0.73
7	0	0	0	1	-1	1.5	0.6	0.6	8	5	1.72±0.17	92.55±0.46
8	0	1	-1	0	0	1.5	0.8	0.4	6	7	1.47±0.12	96.38±0.71
9	1	0	0	-1	0	2.0	0.6	0.6	4	7	1.71±0.18	93.54±0.81
10	0	0	0	1	1	1.5	0.6	0.6	8	9	1.9±0.05	87.67±1.19
11	1	-1	0	0	0	2.0	0.4	0.6	6	7	1.59±0.2	91.06±0.82
12	0	1	0	-1	0	1.5	0.8	0.6	4	7	1.36±0.12	90.05±1.03
13	-1	0	0	0	-1	1.0	0.6	0.6	6	5	1.6±0.1	90.47±2.22
14	0	0	0	-1	1	1.5	0.6	0.6	4	9	1.31±0.06	89.62±1
15	0	-1	0	0	-1	1.5	0.4	0.6	6	5	1.57±0.05	87.7±1.92
16	0	0	1	0	-1	1.5	0.6	0.8	6	5	0.96±0.07	91.37±0.47
17	0	1	0	1	0	1.5	0.8	0.6	8	7	1.19±0.1	92.15±0.46
18	0	1	0	0	-1	1.5	0.8	0.6	6	5	1.36±0.1	93.39±1.66
19	-1	1	0	0	0	1.0	0.8	0.6	6	7	0.96±0.21	89.12±0.64
20	0	1	1	0	0	1.5	0.8	0.8	6	7	0.77±0.2	90.77±0.86
21	-1	0	0	0	1	1.0	0.6	0.6	6	9	1.08±0.18	92.16±3.89
22	1	0	0	0	-1	2.0	0.6	0.6	6	5	1.37±0.07	91.08±1.16
23	0	0	-1	1	0	1.5	0.6	0.4	8	7	1.63±0.02	90.15±1.38
24	0	0	1	0	1	1.5	0.6	0.8	6	9	1.29±0.19	93.19±1.16
25	0	0	0	0	0	1.5	0.6	0.6	6	7	1.27±0.16	93.86±0.31
26	0	0	0	0	0	1.5	0.6	0.6	6	7	1.26±0.17	91.02±0.89
27	0	-1	0	-1	0	1.5	0.4	0.6	4	7	1.13±0.27	94.77±1.26
28	0	1	0	0	1	1.5	0.8	0.6	6	9	1.63±0.29	92.37±1.67
29	1	0	0	0	1	2.0	0.6	0.6	6	9	2.17±0.1	94.83±0.28
30	0	0	-1	0	1	1.5	0.6	0.4	6	9	1.26±0.38	90.84±0.83
31	0	-1	0	0	1	1.5	0.4	0.6	6	9	1.4±0.02	85.56±1.12
32	0	-1	-1	0	0	1.5	0.4	0.4	6	7	1.38±0.09	94±0.18
33	0	0	-1	-1	0	1.5	0.6	0.4	4	7	1.19±0.11	87.59±1.25
34	1	1	0	0	0	2.0	0.8	0.6	6	7	1.3±0.08	88.85±2.71
35	1	0	0	1	0	2.0	0.6	0.6	8	7	1.75±0.05	91.29±1.13
36	0	0	-1	0	-1	1.5	0.6	0.4	6	5	1.73±0.48	90.82±1.38
37	-1	-1	0	0	0	1.0	0.4	0.6	6	7	1.1±0.27	94.22±1.49
38	-1	0	0	1	0	1.0	0.6	0.6	8	7	1.38±0.06	91.92±1
39	-1	0	1	0	0	0.4	0.6	0.8	6	7	0.33±0.01	90.25±1.04
40	0	-1	1	0	0	1.5	0.4	0.8	6	7	0.93±0.14	93.37±1.48
41	0	0	1	1	0	1.5	0.6	0.8	8	7	1.23±0.04	92.91±1.16
42	0	0	0	0	0	1.5	0.6	0.6	6	7	1.28±0.06	93.05±0.71
43	-1	0	0	-1	0	1.0	0.6	0.6	4	7	0.9±0.14	93.6±0.3
44	0	0	0	0	0	1.5	0.6	0.6	6	7	1.27±0.19	91.82±0.34
45	1	0	1	0	0	2.0	0.6	0.8	6	7	1.48±0.09	82.49±0.97
46	0	0	0	0	0	1.5	0.6	0.6	6	7	1.26±0.19	92.96±0.75

试验编号 Test No.	编码水平 Coded levels					实际水平 Actual levels					产量Yield ±SEM （×10⁶ cells/mL）	活细胞比例 FDA±SEM （%）
试验编号 Test No.	A	B	C	D	E	A	B	C	D	E	产量Yield ±SEM （×10⁶ cells/mL）	活细胞比例 FDA±SEM （%）
1	0	-1	0	1	0	1.5	0.4	0.6	8	7	1.65±0.21	90.62±0.77
2	0	0	0	0	0	1.5	0.6	0.6	6	7	1.46±0.14	87.12±1.39
3	-1	0	-1	0	0	1.0	0.6	0.4	6	7	1.52±0.08	88.16±0.96
4	0	0	0	-1	-1	1.5	0.6	0.6	4	5	1.81±0.06	90.31±1.21
5	1	0	-1	0	0	2.0	0.6	0.4	6	7	1.17±0.12	83.5±1.34
6	0	0	1	-1	0	1.5	0.6	0.8	4	7	1.08±0.13	89.2±0.73
7	0	0	0	1	-1	1.5	0.6	0.6	8	5	1.72±0.17	92.55±0.46
8	0	1	-1	0	0	1.5	0.8	0.4	6	7	1.47±0.12	96.38±0.71
9	1	0	0	-1	0	2.0	0.6	0.6	4	7	1.71±0.18	93.54±0.81
10	0	0	0	1	1	1.5	0.6	0.6	8	9	1.9±0.05	87.67±1.19
11	1	-1	0	0	0	2.0	0.4	0.6	6	7	1.59±0.2	91.06±0.82
12	0	1	0	-1	0	1.5	0.8	0.6	4	7	1.36±0.12	90.05±1.03
13	-1	0	0	0	-1	1.0	0.6	0.6	6	5	1.6±0.1	90.47±2.22
14	0	0	0	-1	1	1.5	0.6	0.6	4	9	1.31±0.06	89.62±1
15	0	-1	0	0	-1	1.5	0.4	0.6	6	5	1.57±0.05	87.7±1.92
16	0	0	1	0	-1	1.5	0.6	0.8	6	5	0.96±0.07	91.37±0.47
17	0	1	0	1	0	1.5	0.8	0.6	8	7	1.19±0.1	92.15±0.46
18	0	1	0	0	-1	1.5	0.8	0.6	6	5	1.36±0.1	93.39±1.66
19	-1	1	0	0	0	1.0	0.8	0.6	6	7	0.96±0.21	89.12±0.64
20	0	1	1	0	0	1.5	0.8	0.8	6	7	0.77±0.2	90.77±0.86
21	-1	0	0	0	1	1.0	0.6	0.6	6	9	1.08±0.18	92.16±3.89
22	1	0	0	0	-1	2.0	0.6	0.6	6	5	1.37±0.07	91.08±1.16
23	0	0	-1	1	0	1.5	0.6	0.4	8	7	1.63±0.02	90.15±1.38
24	0	0	1	0	1	1.5	0.6	0.8	6	9	1.29±0.19	93.19±1.16
25	0	0	0	0	0	1.5	0.6	0.6	6	7	1.27±0.16	93.86±0.31
26	0	0	0	0	0	1.5	0.6	0.6	6	7	1.26±0.17	91.02±0.89
27	0	-1	0	-1	0	1.5	0.4	0.6	4	7	1.13±0.27	94.77±1.26
28	0	1	0	0	1	1.5	0.8	0.6	6	9	1.63±0.29	92.37±1.67
29	1	0	0	0	1	2.0	0.6	0.6	6	9	2.17±0.1	94.83±0.28
30	0	0	-1	0	1	1.5	0.6	0.4	6	9	1.26±0.38	90.84±0.83
31	0	-1	0	0	1	1.5	0.4	0.6	6	9	1.4±0.02	85.56±1.12
32	0	-1	-1	0	0	1.5	0.4	0.4	6	7	1.38±0.09	94±0.18
33	0	0	-1	-1	0	1.5	0.6	0.4	4	7	1.19±0.11	87.59±1.25
34	1	1	0	0	0	2.0	0.8	0.6	6	7	1.3±0.08	88.85±2.71
35	1	0	0	1	0	2.0	0.6	0.6	8	7	1.75±0.05	91.29±1.13
36	0	0	-1	0	-1	1.5	0.6	0.4	6	5	1.73±0.48	90.82±1.38
37	-1	-1	0	0	0	1.0	0.4	0.6	6	7	1.1±0.27	94.22±1.49
38	-1	0	0	1	0	1.0	0.6	0.6	8	7	1.38±0.06	91.92±1
39	-1	0	1	0	0	0.4	0.6	0.8	6	7	0.33±0.01	90.25±1.04
40	0	-1	1	0	0	1.5	0.4	0.8	6	7	0.93±0.14	93.37±1.48
41	0	0	1	1	0	1.5	0.6	0.8	8	7	1.23±0.04	92.91±1.16
42	0	0	0	0	0	1.5	0.6	0.6	6	7	1.28±0.06	93.05±0.71
43	-1	0	0	-1	0	1.0	0.6	0.6	4	7	0.9±0.14	93.6±0.3
44	0	0	0	0	0	1.5	0.6	0.6	6	7	1.27±0.19	91.82±0.34
45	1	0	1	0	0	2.0	0.6	0.8	6	7	1.48±0.09	82.49±0.97
46	0	0	0	0	0	1.5	0.6	0.6	6	7	1.26±0.19	92.96±0.75

方差来源 Source of variance	平方和 Sum of squares	自由度 degree of freedom	均方 Mean square	F-value	P-value	显著性 Significance
Model	4.41	20	0.220 3	17.85	<0.000 1	**
A-纤维素酶	0.683 5	1	0.683 5	55.38	<0.000 1	**
B-离析酶	0.031 5	1	0.031 5	2.55	0.122 7	ns
C-甘露醇	0.530 3	1	0.530 3	42.97	<0.000 1	**
D-酶解时间	0.240 1	1	0.240 1	19.45	0.000 2	**
E-根龄	0.000 4	1	0.000 4	0.0324	0.858 6	ns
AB	0.005 6	1	0.005 6	0.4558	0.505 8	ns
AC	0.341 8	1	0.341 8	27.69	<0.000 1	**
AD	0.048 4	1	0.048 4	3.92	0.058 8	ns
AE	0.435 6	1	0.435 6	35.3	<0.000 1	**
BC	0.015 6	1	0.015 6	1.27	0.271 2	ns
BD	0.119	1	0.119	9.64	0.004 7	**
BE	0.048 4	1	0.048 4	3.92	0.058 8	ns
CD	0.021	1	0.021	1.7	0.203 7	ns
CE	0.16	1	0.16	12.96	0.001 4	**
DE	0.115 6	1	0.115 6	9.37	0.005 2	**
A²	0.063	1	0.063	5.11	0.032 8	*
B²	0.017 4	1	0.017 4	1.41	0.246 4	ns
C²	0.162 5	1	0.162 5	13.17	0.001 3	**
D²	0.157 1	1	0.157 1	12.73	0.001 5	**
E²	0.484 4	1	0.484 4	39.25	<0.000 1	**
残差	0.308 5	25	0.012 3
失拟误差	0.277 5	20	0.013 9	2.24	0.189 5	ns
纯误差	0.031	5	0.006 2
总离差	4.71	45

方差来源 Source of variance	平方和 Sum of squares	自由度 degree of freedom	均方 Mean square	F-value	P-value	显著性 Significance
Model	4.41	20	0.220 3	17.85	<0.000 1	**
A-纤维素酶	0.683 5	1	0.683 5	55.38	<0.000 1	**
B-离析酶	0.031 5	1	0.031 5	2.55	0.122 7	ns
C-甘露醇	0.530 3	1	0.530 3	42.97	<0.000 1	**
D-酶解时间	0.240 1	1	0.240 1	19.45	0.000 2	**
E-根龄	0.000 4	1	0.000 4	0.0324	0.858 6	ns
AB	0.005 6	1	0.005 6	0.4558	0.505 8	ns
AC	0.341 8	1	0.341 8	27.69	<0.000 1	**
AD	0.048 4	1	0.048 4	3.92	0.058 8	ns
AE	0.435 6	1	0.435 6	35.3	<0.000 1	**
BC	0.015 6	1	0.015 6	1.27	0.271 2	ns
BD	0.119	1	0.119	9.64	0.004 7	**
BE	0.048 4	1	0.048 4	3.92	0.058 8	ns
CD	0.021	1	0.021	1.7	0.203 7	ns
CE	0.16	1	0.16	12.96	0.001 4	**
DE	0.115 6	1	0.115 6	9.37	0.005 2	**
A²	0.063	1	0.063	5.11	0.032 8	*
B²	0.017 4	1	0.017 4	1.41	0.246 4	ns
C²	0.162 5	1	0.162 5	13.17	0.001 3	**
D²	0.157 1	1	0.157 1	12.73	0.001 5	**
E²	0.484 4	1	0.484 4	39.25	<0.000 1	**
残差	0.308 5	25	0.012 3
失拟误差	0.277 5	20	0.013 9	2.24	0.189 5	ns
纯误差	0.031	5	0.006 2
总离差	4.71	45

方差来源 Source of variance	平方和 Sum of squares	自由度 Degree of freedom	均方 Mean square	F-value	P-value	显著性 Significance
Model	1 416.352	9	157.372 4	105.682 9	1.22E-06	**
A-质粒原生质体配比	74.118 4	1	74.118 4	49.773 98	0.000 201	**
B-PEG浓度	469.367 8	1	469.367 8	315.202 5	4.44E-07	**
C-转化时间	276.491 9	1	276.491 9	185.677 3	2.7E-06	**
AB	14.825 57	1	14.825 57	9.956 065	0.016 033	*
AC	138.661 3	1	138.661 3	93.117 54	2.7E-05	**
BC	220.405	1	220.405	148.012 3	5.8E-06	**
A²	108.933 9	1	108.933 9	73.154 22	5.93E-05	**
B²	341.482 9	1	341.482 9	229.321 8	1.32E-06	**
C²	229.521	1	229.521	154.134 1	5.06E-06	**
残差	10.423 7	7	1.489 099
失拟误差	1.463 695	3	0.487 898	0.217 812	0.879 535	ns
纯误差	8.96	4	2.24
总离差	1 426.775	16
