Precise Editing of the FGF18 Gene in Sheep Fibroblasts Using the AncBE4max System

doi:10.13560/j.cnki.biotech.bull.1985.2025-0454

Abstract

Abstract:

Objective Fibroblast growth factor 18 (FGF18) is a critical regulator of the hair follicle cycle and plays a central role in hair growth and follicle development. However, its function and molecular mechanisms in regulating wool growth remain poorly understood in livestock such as sheep. Therefore, we established an efficient and precise base-editing system for sheep FGF18 to achieve site-specific editing of the FGF18 gene. This study investigates the potential applications of this technology for genetic improvement in agriculture, providing a theoretical foundation for enhancing wool production in the future. Method Three single guide RNAs and their complementary strands were designed and synthesized based on the sequences of exons 3 and 4 of the ovine FGF18 gene in fibroblasts. The annealed sgRNAs were cloned into the pGL3-U6-sgRNA-PGK-puromycin expression plasmid. The U6 expression plasmid containing specific sgRNA and AncBE4max plasmid were co-transfected into ovine fibroblasts via electroporation. Seventy-two hours after transfection, cells were subjected to sequencing verification. Result Results showed that after T-A cloning of the PCR-amplified FGF18 gene fragment, sequencing confirmed the successful introduction of stop codons into exon 3 and 4 of the FGF18 gene. Through screening and identification, two sgRNAs (sg1 and sg3) effectively mediating site-directed editing of the ovine FGF18 gene in fibroblasts were obtained, with editing efficiencies of 13.8% and 36.4%, respectively. Conclusion The established single-base editing system for the ovine fibroblast FGF18 gene, based on the AncBE4max system, enables the precise introduction of stop codons in exon regions. Additionally, two highly efficient editing targets, sgRNA-sg1 and sgRNA-sg3, are successfully screened.

Key words: AncBE4max, fibroblast growth factor 18, gene editing, base editing, sheep fibroblast cells

MENG Ya-qi, WANG Song, YANG Peng, YU Hang, YAO Xu-dong, GUO Yan-hua, TANG Hong, ZHANG Yi-yuan, WANG Li-min, ZHOU Ping. Precise Editing of the FGF18 Gene in Sheep Fibroblasts Using the AncBE4max System[J]. Biotechnology Bulletin, 2025, 41(10): 313-320.

Figures/Tables 10

References 33

[1]	Du YM, Liu YF, Hu JX, et al. CRISPR/Cas9 systems: Delivery technologies and biomedical applications [J]. Asian J Pharm Sci, 2023, 18(6): 100854.
[2]	Zong Y, Song QN, Li C, et al. Efficient C-to-T base editing in plants using a fusion of nCas9 and human APOBEC3A [J]. Nat Biotechnol, 2018.
[3]	王丽洁, 王潇, 杨力, 等. 碱基编辑技术的发展与应用 [J]. 生命的化学, 2019, 39(1): 13-20.
	Wang LJ, Wang X, Yang L, et al. Development and application of base editor [J]. Chem Life, 2019, 39(1): 13-20.
[4]	Zong Y, Wang YP, Li C, et al. Precise base editing in rice, wheat and maize with a Cas9-cytidine deaminase fusion [J]. Nat Biotechnol, 2017, 35(5): 438-440.
[5]	Rees HA, Liu DR. Base editing: precision chemistry on the genome and transcriptome of living cells [J]. Nat Rev Genet, 2018, 19(12): 770-788.
[6]	Li JY, Sun YW, Du JL, et al. Generation of targeted point mutations in rice by a modified CRISPR/Cas9 system [J]. Mol Plant, 2017, 10(3): 526-529.
[7]	Luo L, Shi Y, Wang HN, et al. Base editing in bovine embryos reveals a species-specific role of SOX2 in regulation of pluripotency [J]. PLoS Genet, 2022, 18(7): e1010307.
[8]	Shi Y, Hu BJ, Wang Z, et al. Functional role of GATA3 and CDX2 in lineage specification during bovine early embryonic development [J]. Reproduction, 2023, 165(3): 325-333.
[9]	Ornitz DM, Itoh N. The fibroblast growth factor signaling pathway [J]. Wiley Interdiscip Rev Dev Biol, 2015, 4(3): 215-266.
[10]	Liu ZH, Lavine KJ, Hung IH, et al. FGF18 is required for early chondrocyte proliferation, hypertrophy and vascular invasion of the growth plate [J]. Dev Biol, 2007, 302(1): 80-91.
[11]	Kawano M, Komi-Kuramochi A, Asada M, et al. Comprehensive analysis of FGF and FGFR expression in skin: FGF18 is highly expressed in hair follicles and capable of inducing anagen from telogen stage hair follicles [J]. J Investig Dermatol, 2005, 124(5): 877-885.
[12]	Kimura-Ueki M, Oda Y, Oki J, et al. Hair cycle resting phase is regulated by cyclic epithelial FGF18 signaling [J]. J Investig Dermatol, 2012, 132(5): 1338-1345.
[13]	Plikus MV. New activators and inhibitors in the hair cycle clock: targeting stem cells’ state of competence [J]. J Investig Dermatol, 2012, 132(5): 1321-1324.
[14]	Yu ZS, Ren MD, Wang ZX, et al. Highly efficient genome modifications mediated by CRISPR/Cas9 in Drosophila [J]. Genetics, 2013, 195(1): 289-291.
[15]	Barrangou R . events RNA. Cas9 targeting and the CRISPR revolution [J]. Science, 2014, 344(6185): 707-708.
[16]	潘东霞, 王辉, 熊本海, 等. CRISPR-Cas基因编辑技术在羊生产应用中研究进展 [J]. 遗传, 2024, 46(9): 690-700.
	Pan DX, Wang H, Xiong BH, et al. Progress on CRISPR-Cas gene editing technology in sheep production [J]. Hereditas: Beijing, 2024, 46(9): 690-700.
[17]	Zheng W, Gu F. Progress of application and off-target effects of CRISPR/Cas9 [J]. Yi Chuan, 2015, 37(10): 1003-1010.
[18]	Cong L, Ran FA, Cox D, et al. Multiplex genome engineering using CRISPR/Cas systems [J]. Science, 2013, 339(6121): 819-823.
[19]	Mianné J, Chessum L, Kumar S, et al. Correction of the auditory phenotype in C57BL/6N mice via CRISPR/Cas9-mediated homology directed repair [J]. Genome Med, 2016, 8(1): 16.
[20]	Komor AC, Kim YB, Packer MS, et al. Programmable editing of a target base in genomic DNA without double-stranded DNA cleavage [J]. Nature, 2016, 533(7603): 420-424.
[21]	Xie JK, Ge WK, Li N, et al. Efficient base editing for multiple genes and loci in pigs using base editors [J]. Nat Commun, 2019, 10(1): 2852.
[22]	Lei LQ, Chen HQ, Xue W, et al. APOBEC3 induces mutations during repair of CRISPR-Cas9-generated DNA breaks [J]. Nat Struct Mol Biol, 2018, 25(1): 45-52.
[23]	Kim K, Ryu SM, Kim ST, et al. Highly efficient RNA-guided base editing in mouse embryos [J]. Nat Biotechnol, 2017, 35(5): 435-437.
[24]	Niu YY, Zhao XE, Zhou JK, et al. Efficient generation of goats with defined point mutation (I397V) in GDF9 through CRISPR/Cas9 [J]. Reprod Fertil Dev, 2018, 30(2): 307-312.
[25]	Dang L, Li GL, Wang XJ, et al. Comparison of gene disruption induced by cytosine base editing-mediated iSTOP with CRISPR/Cas9-mediated frameshift [J]. Cell Prolif, 2020, 53(5): e12820.
[26]	钟静丽, 林健香, 周建奎, 等. 碱基编辑系统的研究进展 [J]. 生物工程学报,2024,40(5):1271-1292.
	Zhong JL, Lin JX, Zhou JK, et al. Research progress on base editing systems [J]. Chinese Journal of Biotechnology, 2024, 40(5): 1271-1292.
[27]	Lee HK, Smith HE, Liu CY, et al. Cytosine base editor 4 but not adenine base editor generates off-target mutations in mouse embryos [J]. Commun Biol, 2020, 3(1): 19.
[28]	Thuronyi BW, Koblan LW, Levy JM, et al. Continuous evolution of base editors with expanded target compatibility and improved activity [J]. Nat Biotechnol, 2019, 37(9): 1070-1079.
[29]	Li GW, Zhou SW, Li C, et al. Base pair editing in goat: nonsense codon introgression into FGF5 results in longer hair [J]. FEBS J, 2019, 286(23): 4675-4692.
[30]	Liu ZQ, Chen M, Chen SY, et al. Highly efficient RNA-guided base editing in rabbit [J]. Nat Commun, 2018, 9(1): 2717.
[31]	Molla KA, Yang YN. CRISPR/cas-mediated base editing: technical considerations and practical applications [J]. Trends Biotechnol, 2019, 37(10): 1121-1142.
[32]	周勤, 王爽, 张婷, 等. 小鼠及猕猴胚胎MECP2基因T158M单碱基突变体系的建立 [J]. 中国生物工程杂志, 2020, 40(6):31-39.
	Zhou Q, Wang S, Zhang T, et al. Establishment of a single-base mutation system for the T158M site in the MECP2 gene in mouse and macaque embryos [J]. China Biotechnology, 2020, 40(6): 31-39.
[33]	Zhao JG, Lin HJ, Wang LS, et al. Suppression of FGF5 and FGF18 expression by cholesterol-modified siRNAs promotes hair growth in mice [J]. Front Pharmacol, 2021, 12: 666860.

名称 Name	外显子区域 Exon region	引物序列 Primer sequence （5'-3'）
sg1	第三外显子	F：accgGGAGAACCAGACGCGGGCTC
sg1	第三外显子	R：aaacGAGCCCGCGTCTGGTTCTCC
sg2	第三外显子	F：accgACATCCAGGTCCTGGGCCGC
sg2	第三外显子	R：aaacGCGGCCCAGGACCTGGATGT
sg3	第四外显子	F：accgGGTAGTCAAGTCCGGATCAA
sg3	第四外显子	R：aaacTTGATCCGGACTTGACTACC

名称 Name	外显子区域 Exon region	引物序列 Primer sequence （5'-3'）
sg1	第三外显子	F：accgGGAGAACCAGACGCGGGCTC
sg1	第三外显子	R：aaacGAGCCCGCGTCTGGTTCTCC
sg2	第三外显子	F：accgACATCCAGGTCCTGGGCCGC
sg2	第三外显子	R：aaacGCGGCCCAGGACCTGGATGT
sg3	第四外显子	F：accgGGTAGTCAAGTCCGGATCAA
sg3	第四外显子	R：aaacTTGATCCGGACTTGACTACC

名称 Name	引物序列 Primer sequence （5'-3'）	退火温度 Annealing temperature （℃）	产物长度 Product size （bp）
E3-1	F：GCCAAGCAGGGCAGTTAC	57.9	562
E3-1	R：GGCATTGACCAGCAAGAGTA	57.9	562
E4-1	F：GAGTTGGGAACAGGTGTCA	55.6	588
E4-1	R：CTGCTAAGCAAGCCAGAGT	55.6	588

名称 Name	引物序列 Primer sequence （5'-3'）	退火温度 Annealing temperature （℃）	产物长度 Product size （bp）
E3-1	F：GCCAAGCAGGGCAGTTAC	57.9	562
E3-1	R：GGCATTGACCAGCAAGAGTA	57.9	562
E4-1	F：GAGTTGGGAACAGGTGTCA	55.6	588
E4-1	R：CTGCTAAGCAAGCCAGAGT	55.6	588
